SARV RANG PRODUCT DATA

SARV COAT 1761

pure silicone COATINGS

Description

Sarv coat 1761 is a high temperature resistant, aluminum pigmented primer, based on silicone resin.

Physical Data

Finish............................................... Semi Gloss

Colour............................................. Aluminum

Volume Solids............................... 32±2%

Specific Gravity............................ 1.05 ±0.05 gr/Cm³

Flash Point..................................... 25°C

Recommended D.F.T................... 25-40 microns

Theoretical Coverage................... 12.8-8 sqm/lit

12.19-7.62 sqm/kg

Practical Coverage....................... Depends on loss factor

Touch dry....................................... 2 hrs at 20°C

Hard dry......................................... after thermal curing

Thermal Resistance...................... Continuous 600°C

Noncotinuous 650 °C

Shelf life......................................... 1 year at 25°C

Package.......................................... 20 liter container

Application Details

Application method .................... Air/Airless spray, Brush

Nozzle orifice................................. . .017"

Nozzle pressure............................. 125 bar/1800 Psi

Mixing............................................. Single pack

Thinner/Cleaner............................ SVT-17

Pot life ............................................ N/A

Recoat interval min:.................... 24 hrs at 20 °C

Recoat interval max:................... (see Remarks overleaf)

Outstanding Characteristics

High temperature resistance
Withstanding extreme thermal shocks.
Excellent recoatability without stoving between coats
Good corrosion and weather resistance

Recommended Use

As a general purpose primer, for use in protection of steel surfaces subjected to temperatures up to 600°C.

Surface Preparation

Remove oil and grease, etc. with suitable detergent.

Remove salt and other contaminants by(high pressure) fresh water cleaning.

Abrasive blasting to Sa 2½, SSPC-10.

SARV COAT 1861

acrylic silicone COATINGS

Description

Sarv coat 1861 is a high Temperature resistant, paint, based on modified silicone-acrylic resin.

Physical Data

Finish............................................... Semi Gloss

Colour............................................. aluminium

Volume Solids............................... 38±2%

Specific Gravity............................ 1.05±0.05 gr/Cm³

Flash Point..................................... 25°C

Recommended D.F.T................... 25-40 microns

Theoretical Coverage................... 15.2-9.5 sqm/lit

14.47-9.04 sqm/kg

Practical Coverage....................... Depends on loss factor

Touch dry....................................... 120 min at 20°C

Hard dry......................................... after thermal curing

Thermal Resistance...................... Continuous 400°C

noncontinuous 440 °C

Shelf life......................................... 1 year at 25°C

Package.......................................... 20 liter container

Application Details

Application method .................... Air/Airless spray, Brush

Nozzle orifice................................. . .017"

Nozzle pressure............................. 125 bar/1800 Psi

Mixing ratio................................... Single pack

Thinner/Cleaner............................ SVT-18

Pot life ............................................ N/A

Recoat interval min:.................... 24 hrs at 20 °C

Recoat interval max:................... (see Remarks overleaf)

Outstanding Characteristics

Rust preventing
Excellent sprayability.
Withstanding extreme thermal shocks
Excellent recoatability without stoving between coats
Applicable over zine silicate sarv caot 1983 or directly on blasted steel.

Recommended Use

As a temperature resistant paint, for use in protection of steel surfaces subjected to temperatures up to 400°C.

Surface Preparation

Remove oil and grease, etc. with suitable detergent.

Remove salt and other contaminants by(high pressure) fresh water cleaning.

Abrasive blasting to Sa2½, SSPC-10.

SARV COAT 1862

acrylics silicone COATINGS

Description

Sarv coat 1862 is a temperature resistant, paint, based on modified silicone-acrylic resin.

Physical Data

Finish............................................... Semi Gloss

Colour............................................. Aluminum

Volume Solids............................... 38±2%

Specific Gravity............................ 1±0.05 gr/m³

Flash Point..................................... 25°C

Recommended D.F.T................... 25-40 microns

Theoretical Coverage................... 15.2-9.5 sqm/lit

15.2-9.5 sqm/kg

Practical Coverage....................... Depends on loss factor

Touch dry....................................... 2 hours at 20°C

Hard dry......................................... after thermal curing

Thermal Resistance...................... Continuous 250°C

Shelf life......................................... 1 year at 25°C

Package.......................................... 20 liter container

Application Details

Application method .................... Air/Airless spray, Brush

Nozzle orifice................................. . .017"

Nozzle pressure............................. 125 bar/1800 Psi

Mixing ratio................................... Single pack

Thinner/Cleaner............................ SVT-18

Pot life ............................................ N/A

Recoat interval min:.................... 24 hrs at 20 °C

Recoat interval max:................... (see Remarks overleaf)

Outstanding Characteristics

Rust preventing
Excellent sprayability.
Excellent recoatability without stoving between coats
Applicable over zine silicate sarv caot 1983 or directly on blasted steel.

Recommended Use

As a temperature resistance paint, for use in protection of steel surfaces subjected to temperatures up to 250°C.

Surface Preparation

Remove oil and grease, etc. with suitable detergent.

Remove salt and other contaminants by(high pressure) fresh water cleaning.

Abrasive blasting to Sa ½, SSPC-10.

SARV COAT 1862-7

coloured acrylic silicone COATINGS

Description

Sarv coat 1862-7 is a temperature resistant, paint, based on modified silicone-acrylic resin.

Physical Data

Finish............................................... Semi Gloss

Colour............................................. limited

Volume Solids............................... 41±2%

Specific Gravity............................ 1.05±0.05 gr/cm³

Flash Point..................................... 25°C

Recommended D.F.T................... 25-40 microns

Theoretical Coverage................... 16.4-10.2 sqm/lit

15.6-9.7 sqm/kg

Practical Coverage....................... Depends on loss factor

Touch dry....................................... 2 hours at 20°C

Hard dry......................................... after thermal curing

Thermal Resistance...................... Continuous 250°C

Shelf life......................................... 1 year at 25°C

Package.......................................... 20 liter container

Application Details

Application method .................... Air/Airless spray, Brush

Nozzle orifice................................. . .017"

Nozzle pressure............................. 125 bar/1800 Psi

Mixing ratio................................... Single pack

Thinner/Cleaner............................ SVT-18

Pot life ............................................ N/A

Recoat interval min:.................... 24 hrs at 20 °C

Recoat interval max:................... (see Remarks overleaf)

Outstanding Characteristics

Rust preventing
Excellent sprayability.
Excellent recoatability without stoving between coats
Applicable over zine silicate sarv caot 1983 or directly on blasted steel.

Recommended Use

As a temperature resistant paint, for use in protection of steel surfaces subjected to temperatures up to 250°C.

Surface Preparation

Remove oil and grease, etc. with suitable detergent.

Remove salt and other contaminants by(high pressure) fresh water cleaning.

Abrasive blasting to Sa2½, SSPC-10.

SARV COAT 1862-8

coloured acrylic silicone COATINGS

Description

Sarv coat 1862-8 is a temperature resistant, paint, based on modified silicone-acrylic resin.

Physical Data

Finish............................................... Semi flat-Semi Gloss

Colour............................................. limited Red, Black-Grey, Orange

Volume Solids............................... 41±2%

Specific Gravity............................ 1.05±0.05 gr/m³

Flash Point..................................... 25°C

Recommended D.F.T................... 25-40 microns

Theoretical Coverage................... 16.4-10.2 sqm/lit

15.6-9.7 sqm/kg

Practical Coverage....................... Depends on loss factor

Touch dry....................................... 2 hours at 20°C

Hard dry......................................... after thermal curing

Thermal Resistance...................... Continuous 200°C

Shelf life......................................... 1 year at 25°C

Packageing..................................... 20 liter container

Application Details

Application method .................... Air/Airless spray, Brush

Nozzle orifice................................. . .017"

Nozzle pressure............................. 125 bar/1800 Psi

Mixing ratio................................... Single pack

Thinner/Cleaner............................ SVT-18

Pot life ............................................ N/A

Recoat interval min:.................... 24 hrs at 20 °C

Recoat interval max:................... (see Remarks overleaf)

Outstanding Characteristics

Rust preventing
Excellent sprayability.
Excellent recoatability without stoving between coats
Applicable over zine silicate sarv caot 1983 or directly on blasted steel.

Recommended Use

As a temperature resistant paint, for use in protection of steel surfaces subjected to temperatures up to 200°C.

Surface Preparation

Remove oil and grease, etc. with suitable detergent.

Remove salt and other contaminants by(high pressure) fresh water cleaning.

Abrasive blasting to Sa 2½, SSPC-10.

SARV COAT 1983

3 pack inorcanic zinc silicate COATINGS

Description

Sarv coat 1983 is a 3-pack, self curing(reacting with atmospheric moisture), solvent based zinc ethyl silicate coating.

Physical Data

Finish............................................... Flat

Colour............................................. Grey

Volume Solids............................... 61±2%

Specific Gravity............................ 2.70 ±0.05 gr/m³

Flash Point..................................... 14°C

Zinc content in dry film............... 90±1%

Recommended D.F.T................... 50-75 microns

Theoretical coverage.................... 12.2-8.13 sqm/lit

4.43-2.95 sqm/kg

Practical Coverage....................... depends on loss factor

Touch dry....................................... 10 min

Hard dry......................................... 24 hrs at relative

Humidity up 65-75 %

Thermal Resistance...................... continuous 400°C

Non-continuous 420°C

Shelf life Liquids.......................... 3(part A), 12(part B) months at 20°C

Powder Indefinite

Application Details

Application method .................... Air/Airless spray, Brush

Nozzle orifice................................. . .019"-.023"

Nozzle pressure............................. 100 bar/1500 Psi

Application temperature............. 10 to 40°C

Mixing ratio................................... A/B/C 5/3/25 by weight

Thinner/Cleaner............................ SVT-19

Pot life ............................................ 4 hrs at 20°C

Recoat interval min...................... (see remarks overleaf)

Recoat interval max.................... none(see remarks overleaf)

Outstanding Characteristics

High corrosion and abrasion resistance
Heat resistance up to 420°C.
Suitable for use with a wide range of high performance topcoats.

Recommended Use

As a general purpose, heavy duty rust preventing primer suitable for long term protection of steel structures exposed to severely corrosive and abrasive environment .

Surface Preparation

Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning.

Abrasive blasting to Sa 2½, SSPC-10 with a sharp-edged surface profile corresponding to rugotest No. 3, BN10a, Keane-Tator comparator, 2.0 G/S or ISO comparator medium.(G)

SARV COAT 1983-7

2 Pack inorcanic zinc silicate COATINGS

Description

Sarv coat 1983-7 is a 2-pack, self curing (reacting with atmospheric moisture), solvent based zinc ethyl silicate coating.

Physical Data

Finish............................................... Flat

Colour............................................. Grey

Volume Solids............................... 61±2%

Specific Gravity............................ 2.70 ±0.05 gr/m³

Flash Point..................................... 14°C

Recommended D.F.T................... 50-75 microns

Theoretical coverage.................... 12.2-8.13 sqm/lit

4.43-2.95 sqm/kg

Practical Coverage....................... depends on loss factor

Touch dry....................................... 10 min

Hard dry......................................... 1 days at relative

humidity up 65-75 %

Thermal Resistance...................... continuous 400°C

Non-continuous 420°C

Shelf life Liquids.......................... 3 months at 20°C

Powder ........................... Indefinite

Application Details

Application method .................... Air/Airless spray, Brush

Nozzle orifice................................. . .019"-.023"

Nozzle pressure............................. 100 bar/1500 Psi

Application temperature............. 10 to 40°C

Mixing ratio................................... A/B 8/25 by weight

Thinner/Cleaner............................ SVT-19

Pot life ............................................ 4 hrs at 20°C

Outstanding Characteristics

High corrosion and abrasion resistance
Heat resistance up to 420°C.
Suitable for use with a wide range of high performance topcoats.

Recommended Use

As a general purpose, heavy duty rust preventing primer suitable for long term protection of steel structures exposed to severely corrosive and abrasive environment .

Surface Preparation

Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning.

Abrasive blasting to Sa 2½, SSPC-10 with a sharp-edged surface profile corresponding to rugotest No. 3, BN9a, Keane-Tator comparator, 2.0 G/S or ISO comparator medium.(G)

	SARV COAT 1983-8
2 pack inorcanic zinc silicate shopprimer COATINGS


Description Sarv coat 1983-8 is a three-pack, medium zinc, self curing (reacting with atmospheric moisture), and solvent borne zinc ethyl silicate & weldabel coating.	Physical Data Finish............................................... Flat Colour............................................. Grey Volume Solids............................... 42±2% Specific Gravity............................ 1.65 ±0.1 gr/m³ Flash Point..................................... 10°C Recommended D.F.T................... 20-25 microns Theoretical coverage.................... 21-16.8 sqm/lit 12.7-10.1 sqm/kg Touch dry....................................... 2 hrs Hard dry......................................... 1 days at relative Humidity up 65-75 % Shelf life Liquids.......................... 3 months Powder Indefinite Package.......................................... 5/3/4 liter container Application Details Application method .................... Air/Airless spray, Brush Application temperature............. 5 to 40°C Mixing ratio................................... 1/3/4 by weight Thinner/Cleaner............................ SVT-19 Pot life ............................................ 8 hrs Recoat interval.............................. Min(see remarks overleaf) Max none(see remarks overleaf)
Outstanding Characteristics High corrosion and abrasion resistance Heat resistance up to 420°C. Permits immediate handling, welding, cutting & fabricating.
Recommended Use As a temperature protective primer for the coating of steel work prior to the fabrication & for relatively long term protection of blast cleaned steel plates & other structural steel.
Surface Preparation Remove oil & grease, etc. with suitable detergent Grit blasting to minimum Sa 2½ with a surface profile equivalent to Ragotest No.3, BN10a.

	SARV COAT 1983-9
2 pakc silico silicate primer


Description Sarv coat 1983-9 is a 2-pack, self curing modified ethyl silicate primer. Specially formulated for cold galvanizing of welds & seams.	Physical Data Finish............................................... Flat Colour............................................. Grey Volume Solids............................... 60±1% Specific Gravity............................ 2.70 ±0.5 gr/m³ Flash Point..................................... 10°C Recommended D.F.T................... 40-75 microns Theoretical coverage.................... 15-8 sqm/lit 5.5-2.96 sqm/kg Practical Coverage....................... depends on loss factor Touch dry....................................... 10 min Hard dry......................................... 1 days at relative Humidity up to 50 % Thermal Resistance...................... continuous 400°C Non-continuous 420 °C Shelf life Liquids.......................... 3 months at 25 °C Powder Indefinite Package.......................................... 24 & 8 kg container Application Details Application method .................... Air/Airless spray, Brush Application temperature............. 10 to 40°C Mixing ratio................................... 1 A /3 B Thinner/Cleaner............................ SVT-19 Pot life ............................................ 4 hrs Over coat interval......................... Min.24 hrs(full cured) Max. 3 months
Outstanding Characteristics High corrosion and abrasion resistance Heat resistance up to 400°C. Suitable for use with a wide a range of high performance topcoats.
Recommended Use As a general purpose, leavy duty rust preventing primer, suitable for long term protection of steel structures exposed to severely corrosive and abrasive environment.
Surface Preparation Remove oil & grease, etc. with suitable detergent Grit blasting to minimum Sa 2 ½ with a surface profile equivalent to Ragotest No.3, BN10a.

	SARV COAT 2729
vinyl sealer COATINGS


Description Sarv coat 2729 is a physically drying sealer based on a vinyl copolymer resin.	Physical Data Finish............................................... Flat Colour............................................. Non-pigmented Volume Solids............................... 36±2% Specific Gravity............................ 0.95 ±0.05 gr/m³ Flash Point..................................... 23°C Recommended D.F.T................... 20-40 microns Theoretical coverage.................... 18-9 sqm/lit ......................................................... 18.9-9.5 sqm/kg Practical Coverage....................... depends on loss factor Touch dry....................................... 20 hrs at 20°C Hard dry......................................... 16 hrs at 20 °C Shelf life......................................... 1 year Package.......................................... 4 or 20 liter container Application Details Application method .................... Air/Airless spray, Brush, Roller Application temperature............. 10 - 40°C Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-27 Pot life ............................................ N/A Recoat interval.............................. Min 4 hrs Max 2 moths
Outstanding Characteristics High corrosion resistance and weather resistance High chemical resistance against acids and alkalies With the proper topcoat it withstand splash or spilage of fresh or salt water Excellent penetration
Recommended Use As a sealer coat on metal and concrete surfaces and as intermediate coat on zinc silicates to minimize popping.
Surface Preparation For previously primed surfaces with sarv coat 1983 the surface must be clean and dry. All dirt grease, mill- scales and any other foreign materials should be removed.

	SARV COAT 2730
vinyl anti-fouling COATINGS


Description Sarv coat 2730 is a physically drying anti-fouling topcoat based on a vinyl copolymer resin with a high toxicity level.	Physical Data Finish............................................... Flat Colour............................................. Red Volume Solids............................... 52±2% Specific Gravity............................ 1.6 ±0.1 gr/cm³ Flash Point..................................... 30°C Recommended D.F.T................... 30-50 microns Theoretical coverage.................... 17.3-10.4 sqm/lit 10.8-6.5 sqm/kg Touch dry....................................... 30 min at 20°C Hard dry......................................... 180 min at 35 °C Shelf life......................................... 1 year Package.......................................... 4 & 20 liter container Application Details Application method .................... Air/Airless spray, Brush, Roller Application temperature............. 10 - 40°C Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-27 Pot life ............................................ N/A Recoat interval.............................. Min 24 hrs Max 2 moths
Outstanding Characteristics High toxicity providing excellent anti- fouling property Excellent water resistance Excellent durability
Recommended Use As a anti-fouling topcoat for vinyl system on exterior of immersed marine steel structures and ships.
Surface Preparation The surface must be clean, dry and free from any contamination such as grease, rust, mill scale, salt and loose paint. Old painted surfaces must be cleaned with high pressure water guns.

	SARV COAT 2731
vinyl top coat COATINGS


Description Sarv coat 2731 is a physically drying topcoat based on a vinyl copolymer resin.	Physical Data Finish............................................... Gloss, semi gloss Colour............................................. Upon request Volume Solids............................... 30±2% Specific Gravity............................ 1.20 ±0.05 gr/m³ Flash Point..................................... 23°C Recommended D.F.T................... 30-50 microns Theoretical coverage.................... 10-6 sqm/lit 8.33-5 sqm/kg Practical Coverage....................... depends on loss factor Touch dry....................................... 2 hrs at 20°C Hard dry......................................... 1 days at 20 °C Thermal Resistance...................... 80°C Shelf life......................................... 1 year at 25°C Package.......................................... 20 liter container Application Details Application method .................... Air/Airless spray, Brush, Roller Nozzle orifice................................. . .019"-.021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10 - 40°C Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-27 Pot life ............................................ N/A Recoat interval.............................. Min 24 hrs Max 2 moths
Outstanding Characteristics High corrosion resistance Excellent water resistance Good appearance Good flexibility
Recommended Use As a versatile top coat for vinyl systems on exterior steel structures exposed in moderately to severely industrial and marine corrosive environment.
Surface Preparation The surface must be clean, dry and free from any contamination such as grease, rust, mill scale, salt and loose paint.

	SARV COAT 2732
vinyl intermediate COATINGS


Description Sarv coat 2732 is a physically drying topcoat based on a vinyl copolymer resin.	Physical Data Finish............................................... Flat Colour............................................. upon request Volume Solids............................... 33±2% Specific Gravity............................ 1.35 ±0.05 gr/cm³ Flash Point..................................... 23°C Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 8.25-5.5 sqm/lit 6.11-4.07 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 2 hrs at 20°C Hard dry......................................... 1 days at 20 °C Thermal Resistance...................... 80°C Shelf life......................................... 1 year at 25°C Package.......................................... 20 liter container Application Details Application method .................... Air/Airless spray, Brush, Roller Nozzle orifice................................. . .019"-.021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10 - 40°C Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-27 Pot life ............................................ N/A Recoat interval.............................. Min 24 hrs Max 2 months
Outstanding Characteristics High corrosion resistance Excellent water resistance Good appearance Good flexibility
Recommended Use As a versatile topcoat for vinyl systems on exterior steel structures exposed in moderately to severely industrial and marine corrosive environment.
Surface Preparation The surface must be clean, dry and free from any contamination such as grease, rust, mill scale, salt and loose paint.

	SARV COAT 2733
vinyl zinc chromate primer COATINGS


Description Sarv coat 2733 is a physically drying general primer based on a vinyl copolymer resin pigmented with zinc chromate as corrosion preventing pigment.	Physical Data Finish............................................... Flat Colour............................................. Yellow Volume Solids............................... 32±2% Specific Gravity............................ 1.27 ±0.05 gr/cm³ Flash Point..................................... 23°C Dry film thickness......................... 40-60 microns Theoretical coverage.................... 8-5.3 sqm/lit 6.3-4.2 sqm/kg Touch dry....................................... 2 hrs at 40°C Dry to handle................................. 1 days at 20 °C Thermal Resistance...................... 80°C Practical Coverage....................... depends on loss factor Shelf life......................................... 1 year at 25°C Package.......................................... 4 & 20 liter container Application Details Application method .................... Air/Airless spray, Brush, Roller Nozzle orifice................................. . .019"-.021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10 - 40°C Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-27 Pot life ............................................ N/A Recoat interval.............................. Min 24 hrs Max 2 moths
Outstanding Characteristics High corrosion resistance High water resistance Good flexibility
Recommended Use As a primer for vinly systems on exterior of marine steel structures, or as an intermediate coat on epoxy primer.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Clean damaged area thoroughly by power tool cleaning to ST3 (minor areas) Or by abrasive blasting to minimum SA2, Preferably to SA2 ½ (For repair and maintenance) Abrasive blasting to Sa 2½, SSPC-10 (for new steel)

	SARV COAT 2734
vinyl red lead primer COATINGS


Description Sarv coat 2734 is a physically drying general primer based on a vinyl copolymer resin pigmented with red lead oxide as corrosion preventing pigment.	Physical Data Finish............................................... Flat Colour............................................. Orange Volume Solids............................... 30±2% Specific Gravity............................ 1.53 ±0.05 gr/m³ Flash Point..................................... 23°C Dry Film Thickness....................... 40-60 microns Theoretical coverage.................... 7.5-5 sqm/lit 5-3.26 sqm/kg Touch dry....................................... 2 hrs at 20°C Hard dry......................................... 1 days at 20 °C Thermal Resistance...................... 80°C Practical Coverage....................... depends on loss factor Shelf life......................................... 1 year at 25°C Package.......................................... 4 & 20 liter container Application Details Application method .................... Air/Airless spray, Brush, Roller Nozzle orifice................................. . .019"-.021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10 - 40°C Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-27 Pot life ............................................ N/A Recoat interval.............................. Min 24 hrs Max 2 moths
Outstanding Characteristics High corrosion resistance High water resistance Good flexibility
Recommended Use As a primer for vinyl systems on exterior of marine of marine steel structures, or as an intermediate coat on epoxy primer.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Clean damaged area thoroughly by power tool cleaning to ST3 (minor areas) Or by abrasive blasting to minimum SA2, Preferably to SA2 ½ (For repair and maintenance) Abrasive blasting to Sa 2½, SSPC-10 (for new steel)

	SARV COAT 2735
vinyl red oxie primer COATINGS


Description Sarv coat 2735 is a general purpose vinyl red oxide primer based on vinyl copolymer resin.	Physical Data Finish............................................... Flat Colour............................................. Red-Brown Volume Solids............................... 32±2% Specific Gravity............................ 1.33 ±0.05 gr/m³ Flash Point..................................... 23°C Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 8-5.33 sqm/lit 6.4 sqm/lit Practical Coverage....................... depends on loss factor Touch dry....................................... 2 hrs at 20°C Hard dry......................................... 1 days at 20 °C Shelf life......................................... 1 year at 25°C Thermal Resistance...................... continuous 80°C Package.......................................... 20 liter container Application Details Application method .................... Air/Airless spray, Brush Nozzle orifice................................. . .019"-.021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10 - 40°C Mixing ratio................................... single pack Thinner/Cleaner............................ SVT- 27 Pot life ............................................ N/A Recoat interval.............................. Min 24 hrs Max 2 moths
Outstanding Characteristics Rust Rreventing Excellent sprayability Exellent flexibility. Good Resistance in midly to moderately corrosive environment
Recommended Use As versatile primer for vinyl system on steel structures exposed in moderately to severly industrial & marine corrosive environments.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Clean damaged area thoroughly by power tool cleaning to ST3 (minor areas) Or by abrasive blasting to minimum SA2, Preferably to SA2 ½ (For repair and maintenance) Abrasive blasting to Sa 2½, SSPC-10 (for new steel)

	SARV COAT 2736
vinyl primer COATINGS


Description Sarv coat 2736 is a physically drying general primer based on a vinyl copolymer resin.	Physical Data Finish............................................... Flat Colour............................................. Yellow, other shades may be availabe Volume Solids............................... 34±2% Specific Gravity............................ 1.30 ±0.05 gr/m³ Flash Point..................................... 23°C Dry film thickness......................... 30-50 microns Theoretical coverage.................... 11.33-6.8 sqm/lit 8.71-5.23 sqm/kg Practical Coverage....................... depends on loss factor Touch dry....................................... 2 hrs at 20°C Hard dry......................................... 1 days at 20 °C Thermal Resistance...................... 80°C Shelf life......................................... 1 year at 25°C Package.......................................... 20 liter container Application Details Application method .................... Air/Airless spray, Brush, Roller Nozzle orifice................................. . .019"-.021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10 to 40°C Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-27 Pot life ............................................ N/A Recoat interval.............................. Min 24 hrs Max 2 moths
Outstanding Characteristics High corrosion resistance High water resistance Good flexibility.
Recommended Use As a primer for vinyl systems on exterior steel structures, or as an intermediate coat on sarv coat 1983 to minimize popping.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Clean damaged area thoroughly by power tool cleaning to ST3 (minor areas) Or by abrasive blasting to minimum SA2, Preferably to SA2½ (For repair and maintenance) Abrasive blasting to Sa 2½, SSPC-10 (for new steel)

	SARV COAT 2885
vinyl etch primer COATINGS


Description Sarv coat 2885 is a two component etch primer based on polyvinyl butyral.	Physical Data Finish............................................... Flat Colour............................................. Dark Yellow Volume Solids............................... 12±2% Specific Gravity............................ 0.88 ±0.93 gr/m³ Flash Point..................................... 23°C Recommended D.F.T................... 7-13 microns Theoretical coverage.................... 28-14 sqm/lit 29.47-14.73 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 10 min at 20°C Dry to handle................................. 30 min at 20 °C Shelf life......................................... 1 year at 25 °C Package.......................................... 4 & 16 liter container Application Details Application method .................... Air/Airless spray, Brush, Roller Application temperature............. 10 - 50°C Mixing ratio................................... Base/Hardener 4/ 1 by weight Thinner/Cleaner............................ SVT-28 Pot life ............................................ 5 hours Recoat interval.............................. Min 6 hrs Max 24 moths
Outstanding Characteristics Excellent adhesion to nonferrous surfaces Fast drying, permiting immediate handling High corrosion resistance Compatibility with a wide range of topcoats
Recommended Use As a preconstruction primer and suitable for nonferrous surfaces such as galvanized steel and aluminium, to improve performance of subsequent coats.
Surface Preparation The surface must be clean, and dry. All dirt, grease, mill- scales and any other foreign materials should be removed. Old primed surfaces must be smoothly wire brushed.

	SARV COAT 2968
vinyl decorative COATINGS


Description Sarv coat 2968 is a versatile water base decorative paint based on PVA.	Physical Data Finish............................................... Flat Colour............................................. Upon request Volume Solids............................... 35±2% Specific Gravity............................ 1.4 ±0.05 gr/m³ Recommended D.F.T................... 75 microns Theoretical coverage.................... 4.6 sqm/lit 3.3 sqm/kg Touch dry....................................... 1-2 hrs at 20°C Hard dry......................................... 2-3 dary at 20 °C Practical Coverage....................... Depends on loss factor Shelf life......................................... 1 year Package.......................................... 4 liter container Application Details Application method .................... Air spray, Brush, Roller Application temperature............. 10 - 50°C Mixing ratio................................... single pack Thinner/Cleaner............................ water Pot life ............................................ N/A Recoat interval.............................. Min 5 hrs Max none
Outstanding Characteristics Good colour retention Excellent processability Excellent recoatability Good washability
Recommended Use As a decorative coat on building walls and massonaries.
Surface Preparation The surface must be clean, dry and free from any contamination such as grease, rust, salt and loose paint.

	SARV COAT 3168
ACRYLIC Traffic COATINGS


Description Sarv coat 3168 is a quick drying based on thermoplastic acrylic resin.	Physical Data Finish............................................... Flat Colour............................................. white, yellow, black Volume Solids............................... 49±2% Specific Gravity............................ 1.37±0.05 gr/cm³ Flash point..................................... 33 °C Recommended D.F.T................... 200-400 microns Theoretical coverage.................... 2.4-1.2 sqm/lit. 1.7-0.85 sqm/kg Practical Coverage....................... Depends on loss factor Dry through.................................... 30 min Shelf life ........................................ 12 months Package.......................................... 20 liter container Application Details Application method..................... Automatic spray or hand application Application temperature............. 0-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-31 Pot life ............................................ N/A Recoat interval.............................. No limitation
Outstanding Characteristics High adhesion to concrete and asphalt Excellent abrasion resistance Excellent water and alkali resisance.
Recommended Use Suitable for use on concrete and asphalt, specially for road marking.
Surface Preparation The surface must be clean, dry and free from any contamination such as dust, grease, oil, salt and loose paint.

	SARV COAT 3568
ACRYLIC baking enamel COATINGS


Description Sarv coat 3568 is baking glossy topcoat based on thermoset acrylic resin.	Physical Data Finish............................................... Gloss Colour............................................. Upon rquest Volume Solids............................... 36±3% Specific Gravity............................ 1.15±0.1gr/cm³ Depends on coloul Flash Point..................................... 23°c Dry film thickness......................... 25-40 microns Theoretical coverage.................... 14.4-9 sqm/lit. 12.5-7.8 sqm/kg Practical Coverage....................... Depends on loss factor Flashing time................................. 10 min Stoving conditions........................ 15-20 min at 150-170°c Shelflife ......................................... 12 months at 25°c Package.......................................... 20 liter container Application Details Application method..................... Air/Brush, Roller, deep Nozzle oridice................................ 021” Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 5-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-35 Pot life ............................................ N/A Recoat interval.............................. wet on wet or after partially curing
Outstanding Characteristics High gloss and colour retention Good resistance to different environmental conditions Excellent sprayability High adhesion to different metallic sufaces Excellent flexibility
Recommended Use For use on metal sufaces where a hard, glossy and adherent finish coat is required, specially in home appliances.
Surface Preparation Remove oil grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Clean damaged area thoroughly by power tool cleaning to ST3 (minor areas) Or by abrasive blating to minimum SA2, preferably to SA2 ½ (for repair and maintenance) Abrasive blasting to Sa 2 ½, SSPC-10 (for new steel)

	SARV COAT 3619
ACRYLIC clear COATINGS


Description Sarv coat 3619 is a solvent born clear based on thermoplastic acrylic resin.	Physical Data Finish............................................... Gloss Colour............................................. non pigmented Volume Solids............................... 40±2% Specific Gravity............................ 0.92±0.02 gr/cm³ Flash Point..................................... 33°C Recommended D.F.T................... 30-40 microns Theoretical coverage.................... 13-10 sqm/lit. 14-10.8 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 1 hrs.at 20°c Hard dry......................................... 16 hrs.at 20°c Shelflife ......................................... 12 months at 25°c Package.......................................... 20 liter container Application Details Application method..................... Air/Airless spray, Brush Nozzle orifice................................. .017”- .019” Nozzle pressure............................. 100 bar/1450 Psi Application temperature............. 5-40°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-36 Pot life ............................................ N/A Recoat interval.............................. Min. 3 hrs. Max. Non limitation
Outstanding Characteristics Good gloss effect on to the surfaces. Suitable for interior and exterior.
Recommended Use As a clear coat on metal, wood gypseous and concrete surfaces onto sealer to make surfaces smooth.
Surface Preparation The surface must be clean, dry& free from dust.

	SARV COAT 3620
ACRYLIC topcoat COATINGS


Description Sarv coat 3620 is a quick drying paint based on thermoplastic acrylic resin.	Physical Data Finish............................................... Gloss Colour............................................. Upon request Volume Solids............................... 65±2% Specific Gravity............................ 1.5±0.1gr/cm³ Flash Point..................................... 30°c Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 6.3-9.5 sqm/lit. 8.48-5.56 sqm/kg Heat resistance.............................. 120 °C Practical Coverage....................... Depends on loss factor Touch dry....................................... 2 hrs.at 20°c Hard dry......................................... 14 hrs.at 20°c Shelflife ......................................... 12 months at 25°c Package.......................................... 20 liter container Application Details Application method..................... Air/Airless spray, Brush Nozzle orifice................................. .018”- .021” Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-36 Pot life ............................................ N/A Recoat interval.............................. No limitation
Outstanding Characteristics High gloss and colour retention Good resistance to different environmental conditions Excellent sprayability High adhesion to different metallic surfaces Excellent flexibility
Recommended Use For use as a finish coat on coating system of steel substrates, where a hard, glossy and adherant finish coat is required.
Surface Preparation The surface must be clean, dry and free from any contamination such as dust, grease, oil, salt and loose paint.

	SARV COAT 3621
acrylic primer COATINGS


Description Sarv coat 3621 Is a quick drying primer based on acrylic resin.	Physical Data Finish............................................... Flat Colour............................................. limited Volume Solids............................... 40±2% Specific Gravity............................ 1.30±0.5gr/cm³ Flash Point..................................... 30°c Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 10.5-7 sqm/lit. 7.77-5.18 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 60 min at 20°C Hard dry......................................... 16 hrs at 20°C 14 hrs at 35 °C Shelf life ........................................ 12 months at 25°C Package.......................................... 20 liter container Application Details Application method..................... Air Sprag /Brush, Roller Nozzle oridice................................ .018” - .021” Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 5-40°C Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-36 Pot life ............................................ N/A Recoat interval.............................. No limitation
Outstanding Characteristics Good corrosion resistance Good resistance to different environmental conditions Excellent sprayability High adhesion to different metallic surfaces Excellent flexibility
Recommended Use For use on metal sufaces where a hard conating and corrosion protection is required.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Abrasive blasting to minimum Sa 2 alternatively power tool cleaning to ST3.

	SARV COAT 3622
ACRYLIC putty COATINGS


Description Sarv coat 3622 is a quick drying putty based on thermoplastic acrylic resin.	Physical Data Finish............................................... Flat Colour............................................. Upon request Volume Solids............................... 60±2% Specific Gravity............................ 2.1±0.05 gr/cm³ Flash Point..................................... 70°C Touch dry....................................... 30 min .at 20°c Hard dry......................................... 24 hrs.at 20°c Shelflife ......................................... 12 months at 20°c Package.......................................... 20 liter container Application Details Application method..................... Knife Application temperature............. 0-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-36 Pot life ............................................ N/A Over coating ................................. Min. 24 hrs. Max. Non limitation
Outstanding Characteristics High adhesion to different paints and substrates Good mechanical properties. Excellent flexibility.
Recommended Use Applicable for filling pores & smoothing the concrete and wood and carbon steel surfaces. The consistency can be adjusted by thinner SVT- 36
Surface Preparation The surface must be clean, dry and free from any contaminations such as grease, rust, salt and loose paint.

	SARV COAT 3929
ACRYLIC emulsion sealer COATINGS


Description Sarv coat 3929 is a physically drying penetration primer based on acrylic emulsion resin.	Physical Data Finish............................................... Flat Colour............................................. clear Volume Solids............................... 12±2% Specific Gravity............................ 1.03±0.05 gr/cm³ Recommended D.F.T................... 5-10 microns Theoretical coverage.................... 24-12 sqm/lit. 23.3-11.65 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 30 min. at 20°c 10 min. at 30°C Hard dry......................................... 4 hrs. at 20°C 2 hrs. at 35°C Shelf life ........................................ 12 months Package.......................................... 20 liter container Application Details Application method..................... Air spray, Brush, Roller Nozzle orifice................................. .017”- .021” Nozzle pressure............................. 100 bar/ 1450 Psi Application temperature............. 10-40°c Mixing ratio................................... single pack Thinner/Cleaner............................ water Pot life ............................................ N/A Recoat interval.............................. Min. 4 hrs. Max. Indefinite
Outstanding Characteristics Excellent water resistance Good weather resistance
Recommended Use As a sealer on concrete & masonry substrates for interior and exterior of buildings.
Surface Preparation The surface must be clean, dry and free from any contamination such as grease, salt and loose paint.

	SARV COAT 3930
ACRYLIC emulstion topcoat COATINGS


Description Sarv coat 3930 is a waterborne alkali resistant, acrylic topcoat in ant carbonation system. The product is water- repellent, but allows water vapour from the substrate pass through the film.	Physical Data Finish............................................... Flat Colour............................................. limited Volume Solids............................... 43±2% Specific Gravity............................ 1.45±0.05 gr/cm³ Recommended D.F.T................... 100-150 microns Per two coats Theoretical coverage.................... 4.3-2.86 sqm/lit. 2.96-1.97 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 30 min.at 20°c Hard dry......................................... 5 days at 20°c Shelflife ......................................... 12 months Package.......................................... 20 liter container Application Details Application method..................... Air spray, Brush, Roller Application temperature............. 5-40°c Mixing ratio................................... single pack Thinner/Cleaner............................ water Pot life ............................................ N/A Recoat interval.............................. Min. 6 hrs. Max. None
Outstanding Characteristics Excellent water resistance Good appearance Good flexibility Good weather resistance Good washablity Good U.V resistance
Recommended Use As a topcoat applicable in paint system in interior and exterior of buildings.
Surface Preparation The surface of primer must be clean, dry and free from any contamination such as grease, salt and loose paints.

	SARV COAT 3931
ACRYLIC emulsion primer COATINGS


Description Sarv coat 3931 is a physically drying primer based on acrylic emulsion resin.	Physical Data Finish............................................... Flat Colour............................................. limited Volume Solids............................... 45±2% Specific Gravity............................ 1.45±0.05 gr/cm³ Recommended D.F.T................... 30-50 microns Theoretical coverage.................... 13.3-8 sqm/lit 9.3-5.6 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 30 min .at 20°c Hard dry......................................... 3 days at 20°c Shelf life ........................................ 12 months Package.......................................... 20 liter container Application Details Application method..................... air spray, Brush, Roller Application temperature............. 10-40°c Mixing ratio................................... single pack Thinner/Cleaner............................ water Pot life ............................................ N/A Recoat interval ............................. Min. 6 hrs. Max. None
Outstanding Characteristics Excellent penetrating effect. Promotes adhesion between coating layers & substrate.
Recommended Use As a primer on concrete & masonary interior & exterior of wall and buildings.
Surface Preparation The surface must be clean, dry& free from any contamination such as grease, salt and loose paint.

	SARV COAT 4968
polyester topcoat COATINGS


Description Sarv coat 4968 is baking hard topcoat enamel based on modified saturated polyester resin.	Physical Data Finish............................................... Gloss, semi gloss Colour............................................. Upon request Volume Solids............................... 46±2% Specific Gravity............................ 1.1 ±0.01 gr/cm³ D.F.T............................................... 46-60 microns Flash point..................................... 23 °C Theoretical coverage.................... 11.5-9.2 sqm/lit 9.2-7.36 sqm/kg Practical Coverage....................... Depends on loss factor Flash of time ................................. 10-15 min Baking temperature..................... 150-160 °C Baking timer.................................. 25-30 min Shelf life......................................... 1 year
Outstanding Characteristics Excellent gloss & color retention Excellent sprayability High adhesion to different metallic surfaces Good hardness.
Recommended Use For use on methal surfaces (specially nonferrous metals) where a hard, glossy and adherent finish coat is required, specially in roll coating .
Surface Preparation The surface must be clean, dry and free from rust, mill scale, salt and loose paint. Sand blasting or wire brushing to a standard of ST 2 (SA.2.5, SIS 05 5900, ISO 8501-1) is repuired.

	SARV COAT 6119
alkyd baking clear COATINGS


Description Sarv coat 6119 is a baking glossy clear coat based on a modified alkyd resin.	Physical Data Finish............................................... Gloss Colour............................................. Clear Volume Solids............................... 40±2% Specific Gravity............................ 1±0.05 gr/cm³ Flash Point..................................... 30°C Recommended D.F.T................... 20-40 microns Theoretical coverage.................... 22-11 sqm/lit. 22-11 sqm/kg Practical Coverage....................... Depends on loss factor Flash time....................................... 10 min at 20°C Stoving time................................... 15-20 min at 160°C Shelf life ........................................ 12 months at 25°C Package.......................................... 20 liter container Application Details Application method..................... Air /Airless spray, Brush, Roller, deep Nozzle orfice.................................. .021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°c Thinner/Cleaner............................ SVT-61 Recoat interval.............................. Wet on wet or after . Partially curing
Outstanding Characteristics High gloss and colour retention Excellent sprayability High adhesinon to differente metallic surfaces Excellent flexibility Electrostaticly applicable.
Recommended Use For use on metal surfaces where a hard glossy and adherant finish coat is required, specially in home appliances.
Surface Preparation The surface must be clean & dry. All dirt, grease, mill scales & any other foreign materials should be removed.

	SARV COAT 6120
alkyd baking enamel COATINGS


Description Sarv coat 6120 is a baking glossy topcoat based on a modified alkyd resin.	Physical Data Finish............................................... Gloss, Semi gloss Colour............................................. Upon request Volume Solids............................... 42±3% Specific Gravity............................ 1.15±0.1 gr/cm³ (black: 10) Flash Point..................................... 26°C Recommended D.F.T................... 25-40 microns Theoretical coverage.................... 16.8-10.5 sqm/lit. 14.6-9.1 sqm/kg Practical Coverage....................... Depends on loss factor Flashing time................................. 10 min Stoving time................................... 15-20 min at 160°C Shelf life ........................................ 12 months at 25°C Package.......................................... 20 liter container Application Details Application method..................... Air /Airless spray, Brush, Roller, deep Nozzle orfice.................................. .021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-61 Pot life ............................................ N/A Recoat interval.............................. Wet on wet or after . Partially curing
Outstanding Characteristics High gloss and colour retention Excellent sprayability High adhesion to differente metallic surfaces Excellent flexibility Electrostaticly applicable.
Recommended Use For use on metal surfaces where a hard glossy and adherant oily finish coat is required, specially in home appliances.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Clean damaged area thoroughly by power tool cleaning to ST3 (minor areas) Or by abrasive blasting to minimum Sa2, Preferably to Sa2½ (for repair and maintenance) Abrasive blasting to Sa 2½ SSPC10 -(for new steel)

	SARV COAT 6219
alkyd ureaclear(varnish) COATINGS


Description Sarv coat 6219 is a tow component clear coat based on alkyd urea formaldehyde.	Physical Data Finish............................................... Gloss Colour............................................. no pigmented Volume Solids............................... 58±2% Specific Gravity............................ 1.0±0.05 gr/cm³ Flash Point..................................... 25°C Dry film thickness......................... 40 microns Touch dry....................................... 30 min at 20°C Hard dry ........................................ 48 hrs Theoretical coverage.................... 15 sqm/lit. 15 sqm/kg Practical Coverage....................... Depends on loss factor Shelf life ........................................ 12 months Package.......................................... 4 & 20 liter container Application Details Application method..................... Air Spray Application temperature............. 10-50°c Thinner/Cleaner............................ SVT-62 Mixing ratio................................... 7/1 by weight Pot life ............................................ 8 hours Recoat interval.............................. ---
Outstanding Characteristics Excellent scratch resistance Excellent hardness properties. Good and glossy appearance.
Recommended Use As a clear topcoat for decorating and protecting wood surfaces. The cured film has good stain resistance against cold and hot drinks as well as washing liquids.
Surface Preparation The surface must be clean and dry. All dirt, grease, and any other foreign materials should be removed old primed surfaces must be smoothly brushed by sand paper.

	SARV COAT 6368
alkyd fast drying topcoat COATINGS


Description Sarv coat 6368 is a versatile finish coat based on fast drying alkyd resin.	Physical Data Finish............................................... Gloss , semi gloss Colour............................................. upon request Volume Solids............................... 45±2% Specific Gravity............................ 2.10±0/5 gr/cm³ Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 10-6.6 sqm/lit. 8.7-5.8 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... Max. 45 min at 20°C Hard dry......................................... 1 week at 20°C Shelf life ........................................ 12 months at 25°C Package.......................................... 20 liter container Application Details Application method..................... Air /Airless spray, Brush, Roller Nozzle orifice................................. .018"-.021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°c Mixing ration................................. single pack Thinner/Cleaner............................ SVT-63 Pot life............................................. N/A Recoat interval.............................. Min 15 hrs. Max indefinite
Outstanding Characteristics High gloss and colour retention Fast drying Excellent sprayability Good oil resistance Good resistance in mildly to moderate corrosive environments.
Recommended Use As a finish coat over alkyd primed industrial steel surfaces sush as industrial engines, automobiles, wagons, containers etc
Surface Preparation The surface must be undamaged, clean, dry and free from any contamination such as grease, rust, salt and loose paint.

	SARV COAT 6719
alkyd clear COATINGS


Description Sarv coat 6719 is air-drying alkyd clear.	Physical Data Finish............................................... Gloss Colour............................................. non pigmented Volume Solids............................... 42±2% Specific Gravity............................ 0.9±0.05 gr/cm³ Flash Point..................................... 33°C Dry film thickness......................... 30-35 microns Touch dry....................................... 3 hrs at 20°C Hard dry......................................... 5-7 days at 20°C Theoretical coverage.................... 12-14 sqm/lit 13.30-15.50 sqm/kg Practical coverage........................ depends on loss factor Shelf life ........................................ 1 year at 25°C Package.......................................... 20 liter container Application Details Application method..................... Brush, Roller and Air spray Application temperature............. 10-50°c Thinner/Cleaner............................ SVT-67 Pot life ............................................ N/A Recoat interval.............................. Min. 6 hrs. Max None
Outstanding Characteristics Good gloss effect on to the surfaces. Suitable for interior and exterior.
Recommended Use As a clear coat on metal, wood, gypseous and concrete surfaces onto sealer to make surfaces smooth.
Surface Preparation The surface must be clean, dry & free from dust.

	SARV COAT 6720
alkyd sealer COATINGS


Description Sarv coat 6720 is air-drying alkyd sealer.	Physical Data Finish............................................... semi gloss Colour............................................. non pigmented Volume Solids............................... 40±2% Specific Gravity............................ 1±0.05 gr/cm³ Flash Point..................................... 30°C Dry film thickness......................... 25 microns Touch dry....................................... 2 hrs at 20°C Hard dry......................................... 6 days Theoretical coverage.................... 16.8 sqm/lit. 16 sqm/kg Practical Coverage....................... Depends on loss factor Shelf life ........................................ 12 months at 25°C Package.......................................... 20 liter container Application Details Application method..................... Air Spray, Brush, Roller Application temperature............. 10-50°c Thinner/Cleaner............................ SVT-67 Pot life ............................................ N/A Recoat interval.............................. Min. 1 hrs. Max 2 days
Outstanding Characteristics Excellent penetration effect into the porese. Good bending effect on paint layers.
Recommended Use As a mist coat on metal and sealer coat on concrete surfaces to penetrate into the pores make porous surfaces smooth.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Clean damaged area thoroughly by power tool cleaning to ST3 (minor areas) Or by abrasive blasting to minimum Sa2, preferably to Sa2 ½ (for repair and maintenance) Abrasive blasting to Sa 2½, SSPC-10 (for new steel)

	SARV COAT 6721
alkyd topcoat COATINGS


Description Sarv coat 6721 is a versatile finish coat based on long oil alkyd resin.	Physical Data Finish............................................... semi gloss/ gloss Colour............................................. Upon request Volume Solids............................... 50±2% Specific Gravity............................ 1.15±0.01 gr/cm³ Flash Point..................................... 33°C Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 10.4-6.9 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 3 hrs at 20°C Hard dry......................................... 1 week at 20°C Thermal Resistance...................... 120°C Shelf life ........................................ 1 year at 25°C Package.......................................... 20 liter container Application Details Application method..................... Air /Airless spray, Brush, Roller Nozzle orifice................................. .019”- .021” Nozzle pressure............................. 150 bar/ 2200 Psi Application temperature............. 10-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-67 Pot life ............................................ N/A Recoat interval.............................. Min. 24 hrs. Max indefinite
Outstanding Characteristics Good gloss and colour retention Excellent sprayability Excellent flexibility Good resistance in mildly to moderate environments.
Recommended Use As a finish coat on exterior and interior of steel structures, wood substrates and massonaries, previously primed with alkyd primers.
Surface Preparation The surface must be clean, dry and free from any contamination such as grease, salt and loose paint. Old primed surfaces should be roughened before repainting.

	SARV COAT 6722
alkyd mio interm ediate COATINGS


Description Sarv coat 6722 is a versatile intermediate/finish coat based on long oil alkyd resin.	Physical Data Finish............................................... Flat Colour............................................. Grey Volume Solids............................... 54±2% Specific Gravity............................ 1.45±0.05 gr/cm³ Flash Point..................................... 38°C Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 13.5-9 sqm/lit. 9.3-6.2 sqm/kg Touch dry....................................... 18 min at 20°C 2 hrs at 35°C Hard dry......................................... 1 week at 20°C Thermal Resistance...................... continuous 120°C Practical Coverage....................... Depends on loss factor Shelf life ........................................ 1 year at 25°C Package.......................................... 4 or 20 liter container Application Details Application method..................... Air /Airless spray, Brush, Roller Nozzle orifice................................. .019”- .021” Nozzle pressure............................. 150 bar/ 2200 Psi Application temperature............. 10-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT 67 Pot life ............................................ N/A Recoat interval.............................. Min. 24 hrs. Max 1 months
Outstanding Characteristics Excellent sprayability Good UV resistance Good resistance in mildly to moderate corrosive environments
Recommended Use As an intermediate/finish coat on exterior and interior of steel structures previoush primed with alkyd primers.
Surface Preparation The surface must be clean, dry and free from any contamination such as grease, rust, salt and loose paint. Old primed surfaces should be roughened.

	SARV COAT 6723
alkyd intermediate COATINGS


Description Sarv coat 6723 is a versatile intermediate coat based on long oil alkyd resin.	Physical Data Finish............................................... semi flat/Semi gloss Colour............................................. Upon request Volume Solids............................... 53±2% Specific Gravity............................ 1.2±0.05 gr/cm³ Flash Point..................................... 33°C Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 12-8 sqm/lit. 9.23-6.15 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 180 min at 20°C Hard dry......................................... 7 week at 20°C Thermal Resistance...................... 120°C Shelf life ........................................ 12 months at 25°C Package.......................................... 20 liter container Application Details Application method..................... Air /Airless spray, Brush, Roller Nozzle orifice................................. .019”- .021” Nozzle pressure............................. 150 bar/ 2200 Psi Application temperature............. 10-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-67 Pot life ............................................ N/A Recoat interval.............................. Min. 24 hrs. Max 1 months
Outstanding Characteristics Excellent sprayability Excellent flexibility Good resistance in mildly to moderate corrosire environments.
Recommended Use As an intermediate coat on exterior and interior of steel structures, wood substrates and massonaries, previously primed with alkyd primers.
Surface Preparation The surface must be clean, dry and free from any contamination such as grease, salt and loose paint. Old primed surfaces should be roughened before over coating.

	SARV COAT 6724
alkyd zinc phosphate COATINGS


Description Sarv coat 6724 is a preventing, zinc phosphate pigmented Primer based on long oil alkyd resin.	Physical Data Finish............................................... Flat Colour............................................. Upon request Volume Solids............................... 53±2% Specific Gravity............................ 1.3±0.05 gr/cm³ Flash Point..................................... 33°C Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 12-8 sqm/lit. 8.57-5.71 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 180 min at 20°C Deep dry......................................... 1 week at 20°C Thermal Resistance...................... 120°C Shelf life ........................................ 12 months at 25°C Package.......................................... 20 liter container Application Details Application method..................... Air /Airless spray, Brush, Roller Nozzle orifice................................. .018”- .021” Nozzle pressure............................. 150 bar/ 2200 Psi Application temperature............. 10-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-67 Pot life ............................................ N/A Recoat interval.............................. Min. 24 hrs. Max 1 months
Outstanding Characteristics Excellent Rust preventing Excellent sprayability Excellent flexibility High Resistance in corrosive and humid industrial environments
Recommended Use For use on structural steel e.g building, ware houses, bridges, as part of a suitable alkyd based paint system.
Surface Preparation Remove oil and grease, etc with suitable detergent Remove salt and other contaminants by (high pressure) fresh water cleaning. Abrasive blasting to minimum Sa 2 alternatively power tool cleaning to ST3.

	SARV COAT 6725
alkyd zinc chromate COATINGS


Description Sarv coat 6725 is rust preventing, zinc chromate pigmented primer based on oil alkyd resin.	Physical Data Finish............................................... Flat Colour............................................. Yellow, Green Volume Solids............................... 53±2% Specific Gravity............................ 1.33±0.05 gr/cm³ Flash Point..................................... 33°C Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 12.5-8.3 sqm/lit. 9.25-6.17 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 180 min at 20°C Hard dry......................................... 1 week at 20°C Shelf life ........................................ 12 months at 25°C Thermal Resistance...................... 120°C Package.......................................... 20 liter container Application Details Application method..................... Air /Airless spray, Brush, Roller Nozzle orifice................................. .018”- .021” Nozzle pressure............................. 150 bar/ 2200 Psi Application temperature............. 10-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT 67 Pot life ............................................ N/A Recoat interval.............................. Min. 24 hrs. Max 1 months
Outstanding Characteristics Excellent Rust preventing Excellent sprayability Excellent flexibility High Resistance in corrosive and humid industrial environments
Recommended Use For use on structural steel e.g buildings, ware houses and bridges, as part of a suitable alkyd based paint system.
Surface Preparation Remove oil and grease, etc with suitable sovent. Remove salt and other contaminants by (high pressure) fresh water cleaning. A brasive blasting to minimum Sa 2 alternatively power tool cleaning to ST3.

	SARV COAT 6726
alkyd red oxid rrimer COATINGS


Description Sarv coat 6726 is a general purpose red oxide primer based on long oil alkyd resin.	Physical Data Finish............................................... Flat Colour............................................. Red-Brown Volume Solids............................... 48±2% Specific Gravity............................ 1.5±0.05 gr/cm³ Flash Point..................................... 38°C Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 12-8 sqm/lit. 8-5.3 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 3 hrs at 20°C Hard dry......................................... 1 weak at 20°C Shelf life ........................................ 12 months at 25°C Thermal Resistance...................... 100°C Package.......................................... 20 liter container Application Details Application method..................... Air /Airless spray, Brush, Roller Nozzle orifice................................. .018”- .021” Nozzle pressure............................. 150 bar/ 2200 Psi Application temperature............. 10-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT 67 Pot life ............................................ N/A Recoat interval.............................. Min. 24 hrs. Max 1 months
Outstanding Characteristics Rust preventing Excellent sprayability Excellent flexibility Good Resistance in midly to moderate corrosive environment
Recommended Use For use on structural steel to be topcoated with oil based finish coats.
Surface Preparation Remove oil and grease, etc with suitable detergent Remove salt and other contaminants by (high pressure) fresh water cleaning. A brasive blasting to minimum Sa 2 alternatively power tool cleaning to ST3.

	SARV COAT 6726-9
alkyd red oxide zinc oxide primer COATINGS


Description Sarv coat 6726-9 is a primer based on raw linseed oil and alkyd resin, containing zinc oxide and iron oxide pigments, according to SSPC paint 25 Type II.	Physical Data Finish............................................... Flat-Semi flat Colour............................................. Red Volume Solids............................... 70±1% Specific Gravity............................ 1.5±0.04 gr/cm³ Flash Point..................................... 38°C Recommended D.F.T................... 45-55 microns Theoretical coverage.................... 16-13.1 sqm/lit. 10-8.2 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 20 hrs at 25°C Hard dry......................................... 36 hrs at 25°C Shelf life ........................................ 12 months at 20°C Thermal Resistance...................... 120°C Package.......................................... 20 liter container Application Details Application method..................... Air /Airless spray, Brush, Roller Nozzle orifice................................. .018”- .021” Nozzle pressure............................. 150 bar/ 2200 Psi Application temperature............. 10-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT- 67 Pot life ............................................ N/A Recoat interval.............................. Min. 24 hrs. Max 1 months
Outstanding Characteristics Rust preventing. Excellent recoat ability. High Resistance in mildly to moderate corrosive environment. Not sujtable for immersion.
Recommended Use For use on interior and exterior of structural steel to be top coated with conventional paint systems.
Surface Preparation Remove oil and grease, etc with suitable solvent. Remove salt and other contaminants by (high pressure) fresh water cleaning. A brasive blasting to minimum Sa 2 alternatively power tool cleaning to ST3.

	SARV COAT 6727
alkyd primer COATINGS


Description Sarv coat 6727 is a general purpose primer based on long oil alkyd resin.	Physical Data Finish............................................... Flat Colour............................................. Upon request Volume Solids............................... 57±1% Specific Gravity............................ 1.5±0.05 gr/cm³ Flash Point..................................... 38°C Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 13.75-9.16 sqm/lit. 9.82-6.54 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 3 hrs at 20°C Hard dry......................................... 1 week at 20°C Shelf life......................................... 12 months at 25°C Thermal Resistance...................... 120°C Package.......................................... 20 liter container Application Details Application method..................... Air/Airless spray, Brush, Roller Nozzle orifice................................. . .018"-.021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT- 67 Pot life ............................................ N/A Recoat interval.............................. Min 24 hrs Max 1 months
Outstanding Characteristics Rust Rreventing Excellent sprayalility Excellent flexibility Good Resistance in midly to moderately corrosive environment.
Recommended Use For use on structural steel to be topcoated with oil based finish coats.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Abrasive blasting to minimum Sa 2 alternatively power tool cleaning to ST3.

	SARV COAT 6729
alkyd PHENOLIC TOPCOAT


Description Sarv coat 6729 is a one component alkyd finish coat modified with phenolic.	Physical Data Finish............................................... Flat Colour............................................. Upon request Volume Solids............................... 60±2% Specific Gravity............................ 1.30±0.05 gr/cm³ Flash Point..................................... 23°C Recommended D.F.T................... 50-60 microns Theoretical coverage.................... 12-10 m²/lit. 8-6 m²/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 1 hrs at 25°C Fully cured..................................... 4 days at 25°C Shelf life ........................................ 24 months at 20°C Thermal Resistance...................... Continuous 120°C Non-continuous 130°C Package.......................................... 20 liter container Application Details Application method..................... Air /Airless spray, Brush, Roller Application temperature............. 10-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT- 67 Recoat interval.............................. Min. 24 hrs. Max 72 hrs
Outstanding Characteristics Excellent oil resistance. Excellent chemical resistance against acids alkalis. Excellent adhesion Excellent weather resistance. Excellent Hardness Fast air drying.
Recommended Use As a protection coating in industrial and marine structures over concrete or metal surface. Resistance to a variety of chemicals , fuel oils and solvents. As a general purpose is suitable for lining storage tanks ship tanks exposed to immersion, splash sea mater
Surface Preparation The surface must be clean and dry . All dirt, grease, mill scales and any other foreign materials should be removed. Old primed surfaces must be smoothly wire brushed. Blast to sa 3 ISO 8501 or SSPC 5,the roughness profile should be 40-75 micron.

	SARV COAT 6730
FAST DRYING alkyd TOPCOAT


Description Sarv coat 6730 is a gloss fast drying alkyd topcoat.	Physical Data Finish............................................... Gloss Colour............................................. Upon request Volume Solids............................... 48±2% Specific Gravity............................ 1.2±0.05 gr/cm³ Flash Point..................................... 24°C Recommended D.F.T................... 40-50 microns Theoretical coverage.................... 12.5-9.6 sqm/lit. 10-8 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 15-20 minutes at 20°C Hard dry......................................... 16 hrs at 20°C Fully cured..................................... 14 hrs at 35°C Shelf life ........................................ 12 months at 20°C Thermal Resistance...................... Continuous 90°C Non-continuous 110°C Package.......................................... 20 liter container Application Details Application method..................... Air /Airless spray, Brush, Roller Application temperature............. 5-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT- 67 Pot life ............................................ N/A Recoat interval.............................. Min. 24 hrs. Max 1 months
Outstanding Characteristics Water resistance. Gloss and color retention. Excellent weather ability. Resistance to mild corrosive atmospheric zones .
Recommended Use As a finish coat to be used over Sarv coat 6725 for protection as a topcoat & decorative purposes.
Surface Preparation The surface must be clean , dry and free from any Contamination such as grease , dirt , salt and loose paint. Old primed surfaces should be roughened before repainting.

	SARV COAT 6868
alkyd hich closstopcoat COATINGS


Description Sarv coat 6868 is a general purpose glossy topcoat based on medium oil alkyd resin.	Physical Data Finish............................................... Gloss Colour............................................. Upon request Volume Solids............................... 50±2% Specific Gravity............................ 1.15±0.1 gr/cm³ Viscosity(Ford cup No.4)............. 180±10 sec Flash Point..................................... 30°C Recommended D.F.T................... 40-60 microns Touch dry....................................... 1.5 hrs at 20°C Hard dry......................................... 16 hrs at 20°C Theoretical coverage.................... 12.5-8.3 sqm/lit. 10.8-7.2 sqm/kg Practical Coverage....................... Depends on loss factor Thermal Resistance...................... continuous 120°C Noncontinuous 130°C Shelf life ........................................ 12 months at 20°C Package.......................................... 20 liter container Application Details Application method..................... Air /Airless spray, Brush, Roller Application temperature............. 5-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-68 Pot life ............................................ N/A Recoat interval.............................. Min. 16 hrs. Max indefinite
Outstanding Characteristics High gloss and colour retention Fast drying Excellent sprayability Good oil resistance Good resistance in mildly to moderate corrosive environments.
Recommended Use As a high gloss finish coat over alkyd primed industrial steel surfaces sush as industrial enfines, automobiles, wagons, containers etc...
Surface Preparation The surface must be undamaged, clean, dry and free from any contamination such as grease, rust salt and loose paint.

	SARV COAT 7168
chlorinated rubber swimming pool COATINGS


Description Sarv coat 7168 is a physically drying, modified chlorinated rubber based coating.	Physical Data Finish............................................... Flat Colour............................................. blue and or request Volume Solids............................... 46±2% Specific Gravity............................ 1.25±0.05 gr/cm³ Flash Point..................................... 24°C Recommended D.F.T................... 27-100 microns Theoretical coverage.................... 6.1-4.6 sqm/lit. ......................................................... 4.93-3.70 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 8 hrs at 20°C Shelf life ........................................ 1 year at 25°C Package.......................................... 20 liter container Application Details Application method .................... Air/Airless spray, Brush, Roller. Nozzle orfice.................................. . .021"-.023" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-71 Pot life ............................................ N/A Recoat interval.............................. Min 6 hrs at 20°C Max none (see remarks overleaf)
Outstanding Characteristics Excellent water resistance Fast drying Good penetration. Good appearance.
Recommended Use As a water resistant paint in swimming pools or cementitious water reservoirs.
Surface Preparation The surface must be clean and dry. Remove oil, grease, salt and any other contamination with suitable solvent and by high pressure fresh water.

	SARV COAT 7729
chlorinated rubber sealer COATINGS


Description Sarv coat 7729 is a sealer physically drying, modified chlorinated rubber based.	Physical Data Finish............................................... Flat Colour............................................. non pigmented Volume Solids............................... 36±2% Specific Gravity............................ 1.23±0.05 gr/cm³ Flash Point..................................... 24°C Recommended D.F.T................... 20-40 microns Theoretical coverage.................... 18-9 sqm/lit. 14.63-7.31 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 15 min at 20°C Hard dry......................................... 24 hours at 20°C Thermal Resistance...................... Continuous 60° Non-continuous 65 °C Shelf life ........................................ 12 months at 25°C Package.......................................... 20 liter container Application Details Application method .................... Air/Airless spray, Brush, Roller. Nozzle orfice.................................. . .017"-.021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-77 Pot life ............................................ N/A Recoat interval.............................. Min 6 hrs at 20°C
Outstanding Characteristics Excellent water resistance Durability in severe marine atmosphere Excellent penetration properties.
Recommended Use As a water resistant saler in underwater and above water systems such as ships hulls, decks and superstructures, offshores, structural steel and pipping in chemical plants, refineries, bridges and cranes.
Surface Preparation The surface must be clean and dry. Remove oil, grease, salt and any other contamination with suitable detergent and by high pressure fresh water.

	SARV COAT 7730
chlorinated rubber hich build COATINGS


Description Sarv coat 7730 is a high build physically drying, modified chlorinated rubber based topcoat.	Physical Data Finish............................................... Semi gloss Colour............................................. Upon request Volume Solids............................... 42±2% Specific Gravity............................ 1.25±0.05 gr/cm³ Flash Point..................................... 24°C Recommended D.F.T................... 50-80 microns Theoretical coverage.................... 8.4-5.2 sqm/lit. 6.7-4.2 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 30 min at 20°C Hard dry......................................... 2 hours at 20°C Thermal Resistance...................... Continuous 60° Non-continuous 65 °C Shelf life ........................................ 12 months at 25°C Package.......................................... 20 liter container Application Details Application method .................... Air/Airless spray, Brush, Roller. Nozzle orfice.................................. . .017"-.021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT -77 Pot life ............................................ N/A Recoat interval.............................. Min 6 hrs at 20°C
Outstanding Characteristics Excellent water resistance Durability in severe marine atmosphere Applicable in high film thickness.
Recommended Use As a water resistant coat in underwater and above water systems such as ships hulls, decks and superstructures, offshores, structural steel and pipping in chemical plants, refineries, bridges and cranes. It is also suitable for drinking water systems.
Surface Preparation The surface must be clean, dry and free of grease, mill- scale, rust and dirt.

	SARV COAT 7731
chlorinated rubber top coat COATINGS


Description Sarv coat 7731 is a physically drying, modified chlorinated rubber based topcoat.	Physical Data Finish............................................... Gloss, Semi gloss Colour............................................. Upon request Volume Solids............................... 38±2% Specific Gravity............................ 1.15±0.05 gr/cm³ Flash Point..................................... 24°C Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 9.5-6.3 sqm/lit. 8.3-5.5 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 15 min at 20°C Hard dry......................................... 2 hours at 20°C Thermal Resistance...................... Continuous 60° Non-continuous 65 °C Shelf life ........................................ 1 year at 25°C Package.......................................... 20 liter container Application Details Application method .................... Air/Airless spray, Brush, Roller. Nozzle orifice................................. . .017"-.021" Nozzle pressure............................. 150 bar/2200 Pai Application temperature............. 10-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-77 Pot life ............................................ N/A Recoat interval.............................. Min 6 hrs at 20°C
Outstanding Characteristics Excellent water resistance Durability in severe marine atmosphere Good penetration.
Recommended Use As a water resistant topcoat in underwater and above water systems such as ships hulls, decks and superstructures, offshores, structural steel and pipping in chemical plants, refineries, bridges and cranes. It is also suitable for drinking water systems.
Surface Preparation The surface must be clean, dry and free of grease, mill- scale, rust and dirt.

	SARV COAT 7732
chlorinated rubber MIo interaediate COATINGS


Description Sarv coat 7732 is a physically drying, plastisized chlorinated rubber based intermediate coat, containing M.I.O as a rust preventing pigment.	Physical Data Finish............................................... Flat Colour............................................. Grey Volume Solids............................... 40±2% Specific Gravity............................ 1.25±0.05 gr/cm³ Flash Point..................................... 24°C Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 10-6.6 sqm/lit. 8-5.3 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 30 min at 20°C Hard dry......................................... 2 hours at 20°C Thermal Resistance...................... Continuous 60° Non-continuous 65 °C Shelf life ........................................ 12 months at 25°C Package.......................................... 20 liter container Application Details Air/Airless spray, .......................... Application method Brush, Roller. Nozzle orifice................................. . .017"-.021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-77 Pot life ............................................ N/A Recoat interval.............................. Min 6 hrs at 20°C
Outstanding Characteristics Excellent water resistance Durability in severe marine atmosphere Fast drying.
Recommended Use As a water resistant intermediate coat in underwater and above water systems such as ships hulls, decks and superstructures, offshores, structural steel and pipping in chemical plants, refineries, bridges and cranes. It is also suitable for drinking water systems.
Surface Preparation The surface must be clean, dry and free of grease, mill- scale, rust and dirt.

	SARV COAT 7733
chlorinated rubber intermediate COATINGS


Description Sarv coat 7733 is a physically drying, modified chlorinated rubber based intermediate.	Physical Data Finish............................................... Flat, Semi gloss Colour............................................. Upon request Volume Solids............................... 40±2% Specific Gravity............................ 1.25±0.05 gr/cm³ Flash Point..................................... 24°C Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 10-6.6 sqm/lit. ......................................................... 8-5.3 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 30 min at 20°C Hard dry......................................... 24 hours at 20°C Thermal Resistance...................... Continuous 60° Non-continuous 65 °C Shelf life ........................................ 12 months at 25°C Package.......................................... 20 liter container Application Details Application method .................... Air/Airless spray, Bursh, Roller Nozzle orfice.................................. . .017"-.021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-77 Pot life ............................................ N/A Recoat interval.............................. Min 6 hrs at 20°C
Outstanding Characteristics Excellent water resistance Durability in severe marine atmosphere Good appearance.
Recommended Use As a water resistant intermediate in underwater and above water systems such as ships hulls, decks and superstructures, offshores structural steel and pipping in chemical plants, bridges and cranes. It is also suitable for drinking water systems.
Surface Preparation The surface must be clean, dry and free of grease, mill- scale, rust and dirt.

	SARV COAT 7734
chlorinated rubber zinc chromate primer COATINGS


Description Sarv coat 7734 is a physically drying, modified chlorinated rubber based primer, coating Zinc chromate as rust preventing pigment.	Physical Data Finish............................................... Flat Colour............................................. light.yellow Volume Solids............................... 41±1% Specific Gravity............................ 1.3±0.05 gr/cm³ Flash Point..................................... 24°C Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 11.2-7.5 sqm/lit. 9-6 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 60 min at 20°C Hard dry......................................... 3 hours at 20°C Thermal Resistance...................... Continuous 60° Non-continuous 65 °C Shelf life ........................................ 12 months at 25°C Package.......................................... 20 liter container Application Details Application method .................... Air/Airless spray, Bursh, Roller Nozzle orfice.................................. . .017"-.021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-77 Pot life ............................................ N/A Recoat interval.............................. Min 6 hrs at 20°C
Outstanding Characteristics Excellent water resistance Durability in severe marine atmosphere Good penetration. Excellent acid resistance.
Recommended Use As a maintenance water resistant primer for use on exterior and interior steel surfaces in moderately to severely corrosive environment.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Clean damaged area thoroughly by power tool cleaning to ST2 (minor areas) Or by abrasive blasting to minimum SA2, Preferably to Sa2½ (for repair and maintenance) Abrasive blasting to Sa 2½SSPC-10 (for new steel)

	SARV COAT 7735
chlorinated rubber red lead primer COATINGS


Description Sarv coat 7735 is a physically drying, modified rubber based primer.	Physical Data Finish............................................... Flat Colour............................................. Upon request Volume Solids............................... 40±2% Specific Gravity............................ 1.5±0.05 gr/cm³ Flash Point..................................... 40°C Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 10-6.6 sqm/lit. 7.7-5.1 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 30 min at 20°C Hard dry......................................... 2 hours at 20°C Thermal Resistance...................... Continuous 60°C Non-continuous 65 °C Shelf life ........................................ 12 months at 25°C Package.......................................... 20 liter container Application Details Application method .................... Air/Airless spray, Bursh, Roller Nozzle orfice.................................. . .017"-.021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-77 Pot life ............................................ N/A Recoat interval.............................. Min 6 hrs at 20°C
Outstanding Characteristics Excellent water resistance Durability in severe marine atmosphere Good penetration.
Recommended Use As a maintenance water resistant primer for use on exterior and interior steel surfaces in moderately to severely corrosive environment.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Clean damaged area thoroughly by power tool cleaning to ST3 (minor areas) Or by abrasive blasting to minimum Sa2, Preferably to Sa2½ (for repair and maintenance) Abrasive blasting to Sa 2½SSPC10 -(for new steel)

	SARV COAT 7736
chlorinated rubber red oxide primer COATINGS


Description Sarv coat 7736 is a physically drying modified chlorinated rubber based primer, containing red oxide as rust preventing pigment.	Physical Data Finish............................................... Flat Colour............................................. Red-Brown Volume Solids............................... 45±2% Specific Gravity............................ 1.25±0.05 gr/cm³ Flash Point..................................... 24°C Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 11.2-7.5 sqm/lit. 9-6 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 30 min at 20°C Hard dry......................................... 2 hours at 20°C Thermal Resistance...................... Continuous 60°C Non-continuous 65 °C Shelf life ........................................ 12 months at 25°C Package.......................................... 20 liter container Application Details Air/Airless spray,........................... Application method Brush, Roller Nozzle orfice.................................. . .017"-.021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT- 77 Pot life ............................................ N/A Recoat interval.............................. Min 6 hrs at 25°C
Outstanding Characteristics Excellent water resistance Durability in severe marine atmosphere Good penetration Easy repair.
Recommended Use As a water resistant primer in underwater and above water systems such as ships hulls, decks and superstructures, offshores structures, structural steel and pipping in chemical plants, refineries, bridges and cranes. It is also suitable for drinking water systems.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Clean damaged area thoroughly by power tool cleaning to ST3 (minor areas) Or by abrasive blasting to minimum SA2, Preferably to Sa2½ (for repair and maintenance) Abrasive blasting to Sa 2½SSPC-10(for new steel)

	SARV COAT 7737
chlorinated rubber TRAFFIC PAINT


Description Sarv coat 7737 is a physically drying, modified chlorinated rubber based traffic paint.	Physical Data Finish............................................... Flat Colour............................................. Upon request Volume Solids............................... 40±2% Specific Gravity............................ 1.35±0.05 gr/cm³ Flash Point..................................... 24°C Recommended D.F.T................... 100-150 microns Theoretical coverage.................... 4-2.7 sqm/lit. ......................................................... 2.96-2 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 60 min at 20°C Hard dry......................................... 24 hours at 20°C Thermal Resistance...................... Continuous 60° Non-continuous 65 °C Shelf life ........................................ 12 months at 25°C Package.......................................... 20 liter container Application Details Application method .................... Automatic or hand application Application temperature............. 10-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-77 Pot life ............................................ N/A Recoat interval.............................. No limitation
Outstanding Characteristics Excellent abrasion resistance. Excellent water and alkali resistance Good appearance. High adhesion to concrete and asphalt
Recommended Use Suitable for use on concrete and asphalt , specially for road marking.
Surface Preparation The surface must be clean, dry and free of grease, mill- scale, rust and dirt.

	SARV COAT 7988
chlorinated rubber synthetic primer COATINGS


Description Sarv coat 7988 is a physically quick drying systhetic primer it consist of chlorinated rubber and plasticizer and colouring matter, together with solvents needed to give a consistency suitable for application by spray, brush or other approved method. The technical data meets BS4147 Type "B" requirements.	Physical Data Finish............................................... Gloss Colour............................................. Blak Volume Solids............................... 39±2% Specific Gravity............................ 0.95±0.02 gr/cm³ Flash Point..................................... 24°C Recommended D.F.T................... 30-40 microns Theoretical coverage.................... 9.6-7.5 sqm/lit. 9.47-7.1 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 10 min at 20°C Hard dry......................................... 120 min at 20°C Thermal Resistance...................... Continuous 60° Non-continuous 65 °C Shelf life ........................................ 1 year at 25°C Package.......................................... 20 liter container Application Details Application method .................... Air/Airless spray, Brush, Roller. Nozzle orfice.................................. . .017"-.021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°c Mixing ratio................................... single pack Thinner/Cleaner............................ SVT -79 Pot life ............................................ N/A Recoat interval.............................. Min 6 hrs at 20°C Max none
Outstanding Characteristics Excellent adhesion Quick drying High water resistance.
Recommended Use This synthetic primer for cold and hot application is used with coating materials (usually Hot Bituminous enamel, Hot coal tar enamels and cold wrapping tape) it is quick drying and application of the subsequent coating is possible within a shor time.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Clean damaged area thoroughly by power tool cleaning to ST2 (minor areas) Or by abrasive blasting to minimum SA2, Preferably to Sa2½ (for repair and maintenance) Abrasive blasting to Sa 2½SSPC-10 (for new steel)

	SARV COAT 8150
coaltar Epoxy COATINGS


Description Sarv coat 8150 is a high build two component, corrosion preventing tar-epoxy coating, according to IPS-M-TP-190.	Physical Data Finish............................................... Semi flat – semi gloss Colour............................................. Dark borwn, Black Volume Solids............................... 80±2 Specific Gravity............................ 1.30±0.05 gr/cm³ Flash Point..................................... 26°C Dry film Thicknss......................... 200-400 microns Theoretical Coverage................... 2-4 sqm/lit 1.54-3.08 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... Max. 8 hrs at 20°C Hard dry......................................... Max. 14 days at 20°C Thermal Resistance...................... 140°C Shelf life ........................................ 1 year Package.......................................... 5 & 20 liter container Application Details Application method .................... Air/Airless spray, Brush Nozzle orifice................................. . 0.021"-0.023" Nozzle pressure............................. 200 bar/2900 Psi Application temperature............. 10-50°C Mixing ratio................................... 4/ 1 by weight Cleaner........................................... SVT-18 Pot life ............................................ 8 hrs at 20°C Recoat interval.............................. Min 24 hrs at 20°C Max 72 days at 20°C
Outstanding Characteristics Sarv coat 8150 coal tar epoxy is suitable for use in cold & hot climates It can easily applied in very thick coat. It is excellent rust preventing. Chemical resistance against hydrochloric acid, sodium hydrochloric, salt water and sour crude oil.
Recommended Use For protection of steel in marin structures, pilling , crude oil tanks, ships bottom, pipe coating, power plants, petrochemical & oil refining plants.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Abrasive blasting to Sa 2½ SSPC-10 with a sharp –edged surface profile corresponding to Rugotest No.3, BN9a, Keane- Tator comparator, 2.0 G/S or ISO comparator, medium (G).
Typical recommended paint system 1or2 layers of 100-200 µ each sarv coat 8150 on bare steel 1 layer of epoxy sealer sarv coat 8729-10r2 layers of 100-200 µ each sarv coat 8150 on concrete.

	SARV COAT 8219
Epoxy ester clear COATINGS


Description Sarv coat 8219 is a single pack clear coat based on epoxyester resin.	Physical Data Finish............................................... Gloss Colour............................................. clear Volume Solids............................... 38±2% Specific Gravity............................ 0.95 ±0.05 gr/m³ Flash Point..................................... 23°C Recommended D.F.T................... 20-40 microns Theoretical coverage.................... 19-9.5 sqm/lit 20-10 sqm/kg Practical Coverage....................... depends on loss factor Touch dry....................................... 20 min at 20°C Hard dry......................................... 40 min at 20°C Thermal Resistance...................... 140°C Shelf life......................................... 12 months 25°C Package.......................................... 20 liter container Application Details Application method .................... Air/Airless spray, Brush Nozzle orifice................................. . .019"-.023" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°C Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-82 Pot life ............................................ N/A Recoat interval.............................. Min 24 hrs Max 3 months
Outstanding Characteristics Good adhesion to subsequent coats. Toughness and durability of film. Good resistance against corrosive environments
Recommended Use As a clear coat in industrial and marine structures such as refineries, petrochemical plants, bridges, tanks and water sewage plants.
Surface Preparation The surface must be clean & dry. Any contamination sush as dirt, grease, Oil, salt and any other foreign materials should be removed.

	SARV COAT 8220
Epoxy esters ealer COATINGS


Description Sarv coat 8220 is a single pack sealer based on epoxy ester resin.	Physical Data Finish............................................... Semi gloss Colour............................................. Non- pigmented Volume Solids............................... 42±2% Specific Gravity............................ 1.1 ±0.05 gr/m³ Flash Point..................................... 23°C Recommended D.F.T................... 20-40 microns Theoretical coverage.................... 20-10 sqm/lit 18.18-9.09 sqm/kg Practical Coverage....................... depends on loss factor Touch dry....................................... 30 min at 20°C Hard dry......................................... 48 hrs at 20°C Thermal Resistance...................... 140°C Shelf life......................................... 1 year at 20°C Package.......................................... 20 liter container Application Details Application method .................... Air/Airless spray, Brush Nozzle orifice................................. . .019"-.023" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°C Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-82 Pot life ............................................ N/A Recoat interval.............................. Min 24 hrs ......................................................... Max 3 months
Outstanding Characteristics Excellent penetration Good adhesion to subsequent coats. Toughness and durability of film. Good temperature resistance
Recommended Use As a sealer in industrial and structures such as refineries, petrochemical plants, bridges, tanks and water sewage plants.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Clean damaged area thoroughly by power tool cleaning to ST3 (minor areas) Or by abrasive blasting to minimum SA2, Preferably to SA2 ½ (for repair and maintenance) abrasive blasting to SA 2 ½ SSPC-10 (for new steel)

	SARV COAT 8221
Epoxy Ester top coat COATINGS


Description Sarv coat 8221 is a single pack topcoat based on epoxy ester resin.	Physical Data Finish............................................... Gloss, Semi gloss Colour............................................. Upon uequest Volume Solids............................... 48±2% Specific Gravity............................ 1. 2 ±0.05 gr/cm³ Flash Point..................................... 23°C Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 12-8 sqm/lit 10 -6.7 sqm/kg Partical Coverage......................... depends on loss factor Touch dry....................................... 2 hrs at 20°C 1 hrs at 35°C Hard dry......................................... 16 hrs at 20°C 12 hrs at 35°C Thermal Resistance...................... continuous 100°C Non- continuous 150°C Shelf life......................................... 1 year Package.......................................... 20 liter container Application Details Application method .................... Air/Airless spray, Brush Application temperature............. 10-50°C Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-82 Pot life ............................................ N/A Recoat interval.............................. Min 24 hrs Max 3 hrs
Outstanding Characteristics High colour retention Good adhesion to previous coats. Toughness and durability of film. resistance against corrosive environments
Recommended Use As a topcoat in industrial and marine structures such as refineries, petrochemical plants, bridges, tanks and water sewage plants.
Surface Preparation The surface must be clean and dry. Any contamination such as dirt, grease, oil, salt and any other foreign materials should be removed.

Revised

JUN-2010

	SARV COAT 8222
Epoxy Ester intermediate COATINGS


Description Sarv coat 8222 is a single pack coating based on epoxy ester resin.	Physical Data Finish............................................... semi gloss Colour............................................. Upon uequest Volume Solids............................... 38±2% Specific Gravity............................ 1.33 ±0.05 gr/cm³ Flash Point..................................... 23°C Recommended.............................. 40-60 microns Theoretical coverage.................... 9.5-6.33 sqm/lit 7.14 -4.76 sqm/kg Practical Coverage....................... depends on loss factor Touch dry....................................... 60 min at 20°C Hard dry......................................... 20 hrs at 20°C Thermal Resistance...................... 140°C Shelf life......................................... 1 year at 25°C Package.......................................... 20 liter container Application Details Application method .................... Air/Airless spray, Brush Nozzle orifice................................. . .019"-.023" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°C Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-82 Pot life ............................................ N/A Recoat interval.............................. Min 24 hrs Max 3 months
Outstanding Characteristics High corrosion resistance Good adhesion to previous and subsequent coats. Toughness and durability of film. Good temperature resistance
Recommended Use As a intermediate or topcact in industrial and marine structures such as refineries, petrochemical plants, bridges, tanks and water sewage plants.
Surface Preparation The surface must be clean and dry. Any contamination such as dirt, grease, oil, salt and any other foreign materials should be removed.

	SARV COAT 8223
Epoxy Ester primer COATINGS


Description Sarv coat 8223 is a single pack primer based on epoxy ester resin. Containing corrosi on- resistant pigment.	Physical Data Finish............................................... Creyor other shades Colour............................................. Non- pigmented Volume Solids............................... 43±2% Specific Gravity............................ 1.33 ±0.05 gr/m³ Flash Point..................................... 23°C Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 10.75-7.16 sqm/lit 8.5-38 sqm/kg Practical coverage ....................... dependsonloss factor. Touch dry....................................... 30 min at 20°C Hard dry......................................... 48 hrs at 20°C Thermal Resistance...................... 140°C Shelf life......................................... 1 year at 20°C Package.......................................... 20 liter container Application Details Application method .................... Air/Airless spray, Brush Nozzle orifice................................. . .019"-.023" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°C Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-82 Pot life ............................................ N/A Recoat interval.............................. Min 24 hrs Max 3 hrs
Outstanding Characteristics High corrosionresis tance Good adhesion to subsequent coats. Toughness and durability of film. Good processbility.
Recommended Use As a prlmer in industrial and marlne structures such as refineries, petrochemical plants, bridges, tanks and water sewage plants.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Clean damaged area thoroughly by power tool cleaning to ST3 (minor aress) Or by abrasive blasting to minimum SA2, Preferably to Sa2 ½ (for repair and maintenance) abrasive blasting to Sa 2 ½ SSPC-10 (for new steel)

	SARV COAT 8568
polyamine cured Epoxy VinyL topcoat COATINGS


Description Sarv coat 8568 is a physically drying topcoat based on a vinyl copolymer resin.	Physical Data Finish............................................... Gloss, semi gloss Colour............................................. Upon request Volume Solids............................... 41±2% Specific Gravity............................ 1.1 ±0.05 gr/cm³ Flash Point..................................... 25°C Recommended D.F.T................... 30-50 microns Theoretical coverage.................... 13.6-8.2 sqm/lit 12.4-7.45 sqm/kg Practical Coverage....................... depends on loss factor Touch dry....................................... Max 2 hrs at 20°C Fully cured..................................... 7 days at 20°C Thermal Resistance...................... 140°C Shelf life......................................... 1 year at 25°C Package.......................................... 5& 20 liter container Application Details Application method .................... Air/Airless spray, Brush Nozzle orifice................................. . .021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 5-50°C Mixing ratio................................... 4/1 by weight Thinner/Cleaner............................ SVT- 85 Pot life ............................................ 8 hrs at 20°C Recoat interval.............................. Min 24 hrs Max 4 months
Outstanding Characteristics High corrosion resistance Excellent water resistance. Good appearance. Good flexibility.
Recommended Use As a versatile topcoat for vinyl systems on exterior steel structures exposed in moderately to severely industrial and marine corrosive environment.
Surface Preparation The surface must be clean, dry and free from any contamination such as grease, rust, mill scale, salt and loose paint.

	SARV COAT 8569
hich build Epoxy VinyL intermediate COATINGS


Description Sarv coat 8569 is a two component, vinyl polyamide cured epoxy intermediate.	Physical Data Finish............................................... semi gloss Colour............................................. Upon request Volume Solids............................... 42±2% Specific Gravity............................ 1.1 ±0.05 gr/m³ Flash Point..................................... 26°C Recommended D.F.T................... 50-70 microns Theoretical coverage.................... 8.4-6.0 sqm/lit ......................................................... 7.6-5.45 sqm/kg Practical Coverage....................... depends on loss factor Touch dry....................................... Max 2 hrs at 20°C Fully cured..................................... 7 days at 20°C Thermal Resistance...................... 140°C Shelf life......................................... 1 year at 25°C Package.......................................... 5& 20 liter container Application Details Application method .................... Air/Airless spray, Brush Nozzle orifice................................. . .021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 5-50°C Mixing ratio................................... 4/1 by weight Thinner/Cleaner............................ SVT-85 Pot life ............................................ 8 hrs at 20°C Recoat interval.............................. Min 24 hrs Max 4 months
Outstanding Characteristics Good UV resistance Excellent chemical resistance against weak acids and alkalis. Suitable as finish coat in various paint systems. Corrosion resistance in moderately to severely environment.
Recommended Use As a protective intermediate coat in industrial and marine structures, over concrete or metal surfaces.
Surface Preparation The surface must be clean and dry. All dirt, grease mill- scales and any other foreign materials should be removed. Old primed surfaces must be smoothly wire brushed.

	SARV COAT 8570
Epoxy VinyL hich build intermediate COATINGS


Description Sarv coat 8570 is a two component, polyamide cured epoxy- vinyl intermediate coat. Also suitable suitable as "Tie coat" between epoxy & physically drying coating.	Physical Data Finish............................................... semi gloss Colour............................................. Upon request Volume Solids............................... 53±2% Specific Gravity............................ 1.3 ±0.05 gr/m³ Flash Point..................................... 26°C Recommended D.F.T................... 50-100 microns Theoretical coverage.................... 10.6-5.3 sqm/lit 8.1-4.1 sqm/kg Practical Coverage....................... depends on loss factor Touch dry....................................... Max 2 hrs at 20°C Fully cured..................................... 7 days at 20°C Thermal Resistance...................... 140°C Shelf life......................................... 1 year at 25°C Package.......................................... 5& 20 liter container Application Details Application method .................... Air/Airless spray, Brush Nozzle orifice................................. . .021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 5-50°C Mixing ratio................................... 4/1 by weight Thinner/Cleaner..................................... SVT- 85 Pot life ............................................ 8 hrs at 20°C Recoat interval.............................. Min 24 hrs Max 4 months
Outstanding Characteristics Excellent oil resistance Excellent chemical resistance against weak acids and alkalis. Suitable as 2nd coat in various paint systems. Corrosion resistance in moderately to severely atmosphere.
Recommended Use As a protective intermediate coat for industrial and marine structures, over epoxy & zinc ethyl silicate primer.
Surface Preparation The surface must be clean and dry. All dirt, grease & any other foreign matter should be removed. Old primed surfaces must be smoothly wire brushed.

	SARV COAT 8571
Epoxy VinyL hich bulid primer COATINGS


Description Sarv coat 8571 is a two component, vinyl polyamida cured epoxy primer.	Physical Data Finish............................................... Flat Colour............................................. Upon request Volume Solids............................... 44±2% Specific Gravity............................ 1.15 ±0.05 gr/cm³ Flash Point..................................... 23°C Recommended D.F.T................... 70-80 microns Theoretical coverage.................... 6.28-5.5 sqm/lit 5.46-4.78 sqm/kg Practical Coverage....................... depends on loss factor Touch dry....................................... Max 2 hrs at 20°C Fully cured..................................... 7 days at 20°C Thermal Resistance...................... 140°C Shelf life......................................... 1 year at 25°C Package.......................................... 5& 20 liter container Application Details Application method .................... Air/Airless spray, Brush Nozzle orifice................................. . .021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 5-50°C Mixing ratio................................... 4/1 by weight Thinner/Cleaner............................ SVT-85 Pot life ............................................ 8 hrs at 20°C Recoat interval.............................. Min 24 hrs Max 4 months
Outstanding Characteristics Good UV resistance Excellent chemical resistance against weak acids and alkalis. Suitable as finish coat in various paint systems. Corrosion resistance in moderately to severely environment.
Recommended Use As a protective intermediate coat in industrial and marine structures, over concrete or metal surfaces.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Clean damaged area thoroughly by power tool cleaning to ST3 (minor aress) Or by abrasive blasting to minimum SA2, Preferably to SA2 ½ (for repair and maintenance) abrasive blasting to SA 2 ½ SSPC-10 (for new steel)

	SARV COAT 8572
Epoxy VinyL zing dust primer COATINGS


Description Sarv coat 8572 is a two component, polyamide cured epoxy modified by vinyl containing zinc dust.	Physical Data Finish............................................... Flat Colour............................................. Upon request Volume Solids............................... 58±2% Specific Gravity............................ 1.8 ±0.05 gr/m³ Flash Point..................................... 23°C Recommended D.F.T................... 70-80 microns Theoretical coverage.................... 8.2-7.2 sqm/lit 4.6-4.0 sqm/kg Practical Coverage....................... depends on loss factor Touch dry....................................... Max 2 hrs at 20°C Fully cured..................................... 7 days at 20°C Thermal Resistance...................... 140°C Shelf life......................................... 1 year at 25°C Package.......................................... 5& 20 liter container Application Details Application method .................... Air/Airless spray, Brush Nozzle orifice................................. . .021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 5-50°C Mixing ratio................................... 4/1 by weight Thinner/Cleaner............................ SVT- 85 Pot life ............................................ 8 hrs at 20°C Recoat interval.............................. Min 24 hrs Max 4 months
Outstanding Characteristics Excellent chemical resistance against weak acids and alkalis. Suitable as finish coat in various paint systems. Corrosion resistance in moderately to severely environment.
Recommended Use As a protective primer coat in industrial and marine structures, over concrete or metal surfaces.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Clean damaged area thoroughly by power tool cleaning to ST3 (minor aress) Or by abrasive blasting to minimum SA2, Preferably to SA2 ½ (for repair and maintenance) abrasive blasting to SA 2 ½ SSPC-10 (for new steel)

	SARV COAT 8573
epoxy vinyl zinc phosphte primer COATINGS


Description Sarv coat 8573 is a two component, polyamide cured epoxy vinyl primer, containing zinc phosphate as corrosion inhibiting pigment.	Physical Data Finish............................................... Flat Colour............................................. Yellow, Grey, Green Volume Solids............................... 53±2% Specific Gravity............................ 1.3±0.05 gr/cm³ Flash Point..................................... 26°C Recommended D.F.T................... 40-60 microns Theoretical Coverage................... 13.3-8.8 sqm/lit 10.2-6.8 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 2 hours at 20°C 1 hrs at 35°C Fully cured..................................... 7 days at 20°C 6 days at 35°C Thermal Resistance...................... 140°C Shelf life......................................... 1 year at 20°C Package.......................................... 4 & 20 liter container Application Details Application method .................... Air/Airless spray, Brush Nozzle orifice................................. . .021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 5-50 °C Mixing ratio................................... 4 /1 by weight Thinner/Cleaner............................ SVT-85 Pot life ............................................ 8 hrs at 20 °C Recoat interval:............................ Min 24 hrs Max 4 months
Outstanding Characteristics Suitable for application on blasted or galvanized steel. Good cutting and welding properties. Suitable as a first coat in various paint systems Suitable for application under humid condition.
Recommended Use As a general purpose rust preventing primer, for epoxy and urethane systems on steel and other metal surfaces.
Surface Preparation Sand blasting or wire brushing to a standard of ST2(SA 2.5, SIS 05 5900, ISO 8501-1) is perquisite.

	SARV COAT 8574
Epoxy vinyl Primer COATINGS


Description Sarv coat 8574 is a two component, polyamide cured epoxy vinyl primer coat.	Physical Data Finish............................................... Flat Colour............................................. Upon request Volume Solids............................... 52±2% Specific Gravity............................ 1.35 ±0.05 gr/m³ Flash Point..................................... 26°C Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 13-8.7 sqm/lit 9.62-6.41 sqm/kg Practical Coverage....................... depends on loss factor Touch dry....................................... Max 2 hrs at 20°C Fully cured..................................... 7 days at 20°C Thermal Resistance...................... 140°C Shelf life......................................... 1 year at 25°C Package.......................................... 5- 20 liter container Application Details Application method .................... Air/Airless spray, Brush Nozzle orifice................................. . .021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 5-50°C Mixing ratio................................... 4/1 by weight Thinner/Cleaner............................ SVT-85 Pot life ............................................ 8 hrs at 20°C Recoat interval.............................. Min 24 hrs Max 4 months
Outstanding Characteristics Excellent oil resistance Excellent chemical resistance against weak acids and alkalis. Suitable as 2^nd coat in various epoxy paint systems. Corrosion resistance in moderately to severely coastal atmosphere.
Recommended Use As a protective primer coat for industrial and marine structures.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Clean damaged area thoroughly by power tool cleaning to ST3 (minor aress) Or by abrasive blasting to minimum SA2, Preferably to SA2 ½ (for repair and maintenance) abrasive blasting to SA 2 ½ SSPC-10 (for new steel)

	SARV COAT 8729
Epoxy polyamide sealer COATINGS


Description Sarv coat 8729 is a two component polyamide cured, epoxy sealer. It is possible to formulate with MIO and without MIO.	Physical Data Finish............................................... Semi flat Colour............................................. Red oxide Volume Solids............................... 57±2% Specific Gravity............................ 1.4 ±0.05 gr/m³ Flash Point..................................... 27°C Dry Film Thickness....................... 40-60 microns Touch dry....................................... 2 hrs at 20°C Hard dry(fully cured)................... 1 week at 20°C Thermal Resistance...................... 140 °C Theoretical coverage.................... 14.25-9.5 sqm/lit 10.17-6.78 sqm/kg Practical Coverage....................... Depends on loss factor Shelf life......................................... 12 months at 25°C Package.......................................... 5 & 20 liter container Application Details Application method, ................... Air/Application spray, Brush Nozzle orifice................................. .019”-.021” Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°C Mixing ratio................................... 4/1 by weight Thinner/Cleaner............................ SVT-87 Pot life ............................................ 8 hrs at 20°C Recoat interval:............................ min 6 hrs max none
Outstanding Characteristics Excellent penetration. High chemical & solvent resistance With the proper topcoat it withstands splash or spillage of water.
Recommended Use As sealer coat on metal surfaces and as an intermediate coat on zinc silicates to minimize popping.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Clean damage area thoroughly by power tool cleaning to ST3 (minor areas) Or by abrasive blasting to minimum SA2, preferably to SA2½(for repair and maintenance) Abrasive blasting to Sa2½SSPC-10 (for new steel)

	SARV COAT 8729-7
Epoxy polyamide sealer/fuller COATINGS


Description Sarv coat 8729-7 is a two component, polyamide cured epoxy sealer.	Physical Data Finish............................................... Glossy Colour............................................. None Volume Solids............................... 57±2% Specific Gravity............................ 1.2±0.05 gr/cm³ Flash Point..................................... 27°C Dry Film Thickness....................... 20-40 microns Touch dry....................................... 2-4 hrs at 20°C Hard dry (fully cured).................. 7 days at 20°C Thermal Resistance...................... 140°C Theoretical coverage.................... 28.5-14.25 sqm/lit. 23.75-11.87 sqm/kg Practical Coverage....................... Depends on loss factor Shelf life ........................................ 1 year at 25°C Application Details Application method .................... Air/Airless spray, Bursh Nozzle orifice................................. . .017"-.021" Nozzle pressure............................. 100 bar/1450 Psi Application temperature............. 10-50°C Mixing ratio................................... 4/1 by weight Thinner/Cleaner............................ SVT-87 Pot life ............................................ 8 hrs at 20°C Recoat interval.............................. Min 6 hrs at 20°C Max none
Outstanding Characteristics Excellent penetration High chemical & solvent resistance With the proper topcoat it withstands splash or spillage of water.
Recommended Use As a sealer coat on metal surfaces, concrete and as a tie coat on ethyl silicate primer.
Surface Preparation The surface must be clean & dry. All dirt, Grease, mill scales and any other foreign materials should be removed. In the case of flooring the surface shall be scraped by appropriate tools.

	SARV COAT 8729-8
Epoxy polyamide sealer COATINGS


Description Sarv coat 8729-8 is a two component, polyamide cured epoxy sealer.	Physical Data Finish............................................... Glossg Colour............................................. Transparent Volume Solids............................... 40% Specific Gravity............................ 0.90±0.05 gr/cm³ Flash Point..................................... 24°C Dry Film Thickness....................... 20-40 microns Touch dry....................................... 2-3 hrs at 20°C Hard dry (fully cured).................. 7 days at 20°C Thermal Resistance...................... 140°C Theoretical coverage.................... 22.5-11.25 sqm/lit. 23-11.4 sqm/kg Practical Coverage....................... Depends on loss factor Shelf life ........................................ 1 year at 25°C Application Details Application method .................... Air/Airless spray, Bursh Nozzle orifice................................. . .013"-.017" Nozzle pressure............................. 100 bar/1450 Psi Application temperature............. 10-50°C Mixing ratio................................... 3/1 by weight Thinner/Cleaner............................ SVT-87 Pot life ............................................ 8 hrs at 20°C Recoat interval.............................. Min 6 hrs at 20°C Max none
Outstanding Characteristics Excellent penetration High chemical & solvent resistance High electrical conductivity.
Recommended Use As a sealer coat on concrete, steel substrate & floors subjected electrical conductivity.
Surface Preparation The surface must be clean and dry. All dirt, Grease, mill scales and any other foreign materials should be removed. In the case of flooring the surface shall be scraped by appropriate tools.

	SARV COAT 8730
Epoxy polyamide high build MIO COATINGS


Description Sarv coat 8730 is a two component polyamide cured, high build epoxy coating, containing micaceous iron oxide.	Physical Data Finish............................................... Semi flat Colour............................................. light grey & Red Volume Solids............................... 58%(ASTM-D-2697 modified) Specific Gravity............................ 1.36 kg/L(white) Flash Point..................................... 24°C Dry Film Thickness....................... 75-125 sqm/lit Touch dry....................................... 1 hrs at 20°C Hard dry......................................... 7 days at 20°C 6 days at 35°C Thermal Resistance...................... 140 °C Theoretical coverage.................... 7.6- 4.5 sqm/lit ......................................................... 5.2- 3.1 sqm/kg Practical Coverage....................... Depends on loss factor Shelf life......................................... 1 year at 25°C Package.......................................... 5 & 20 liter container Application Details Air/Airless spray, .......................... Air/Application spray, Brush Nozzle orifice................................. .019”-.021” Nozzle pressure............................. 150 bar/2200 Psi Mixing ratio................................... 4/1 by weight Thinner/Cleaner............................ SVT-87 Pot life ............................................ 8 hrs at 20°C
Outstanding Characteristics Suitable for application on blasted steel High abrasion and chemical resistance Good cutting and welding properties Suitable for application under humid condition.
Recommended Use For protection of structural steel in refineries, mining pulp and paper industries, water sewage plants, bridges, storage tanks and peteochemical plants.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. (For maintenacce) Abrasive blasting to Sa 2½ , SSPC-10 with a sharp-edged surface profile corresponding to rugotest No.3, BN9a, keane – Tator comparator, 2.0 G/S or ISO comparator, medium(G). (For new steel)

	SARV COAT 8731
Epoxy polyamide high build/high solid self primer COATINGS


Description Sarv coat 8731 is a two component polyamide cured, high build epoxy primer & intermediate, containing zinc phosphate as corrosion inhigiting pigment.	Physical Data Finish............................................... Semi gloss Colour............................................. Upon request Volume Solids............................... 85% (ASTM-D-2697 modified) Specific Gravity............................ 1.31 kg(mixed produet) Flash Point..................................... 24°C Dry Film Thickness....................... 125 microns per coat Theoretical coverage.................... 6.8 m²/L at 125 microns Touch dry....................................... 6 hrs at 20°C Hard dry......................................... 7 days 20°C 5 days at 35°C Thermal Resistance...................... 140 °C Practical Resistance..................... depends on loss factor Shelf life......................................... 1 year at 25°C Package.......................................... 5 & 20 liter container Application Details Application method .................... Air/Airless spray, Brush Nozzle orifice................................. .021” Nozzle pressure............................. 50 bar/3600 Psi Mixing ratio................................... Base/Hardener 4/1/ by weight Thinner/Cleaner............................ SVT-87 Pot life ............................................ 8 hrs at 20°C Recoat interval min:.................... (24 hrs at 20°C) Recoat interval max:................... (14 days at 20°C)
Outstanding Characteristics Suitable for application on blasted steel Good cutting and welding properties Suitable as a first coat in various paint systems Suitable for application under humid condition. Suitable for water immersion.
Recommended Use As a high build, rust preventing primer & intermediate for epoxy and urethane systems on steel and other metal surfaces.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Abrasive blasting to Sa 2½, SSPC-10 with a sharp-edged surface profile corresponding to rugotest No.3, BN9a, keane – Tator comparator, 2.0 G/S or ISO comparator, medium(G).

SARV COAT 8732

Epoxy polyamide high build COATINGS

Description

Sarv coat 8732 is a two component polyamide cured, high build epoxy coating, applicable as intermediate & topcoat.

Physical Data

Finish............................................... Semi gloss

Colour............................................. Upon request

Volume Solids............................... 65±2%

Specific Gravity............................ 1.40±0.05 gr/cm³

Flash Point..................................... 26°C

Recommended D.F.T................... 100-125 microns

Theoretical coverage.................... 6.5- 5.2 m²/lit

4.6- 3.7 m²/kg

Practical Coverage....................... Depends on loss factor

Touch dry....................................... 2 hrs at 20°C

Fully cured..................................... 1 week at 20°C

Thermal Resistance...................... Continuous 110 °C

Non-Continuous 130°C

Shelf life......................................... 24 month at 20°C

Package.......................................... 4 & 20 liter container

Application Details

Application method .................... Air/Airless spray, Brush

Nozzle orifice................................. . .019" - .021"

Nozzle pressure............................. 150 bar/2200 Psi

Application temperature............. .10-50°C

Mixing ratio................................... Refer to the can label

Thinner/Cleaner............................ SVT-87

Pot life ............................................ 4 hrs at 20°C

Recoat interval.............................. Min 24 hrs

Max 72 hrs

Outstanding Characteristics

Excellent oil resistance
Excellent chemical resistance against weak acids and alkalies
Resistance to transit and handling damages
Corrosion resistance in moderately to severely to severely marine & industrial environment

Recommended Use

As a high build, high performance protective coating in aggressive environment over concrete or metal substrate (interior and exterior surfaces).

Surface Preparation

The surface must be clean and dry.All dirt,grease,mill-scales and any other foreign materials should be removed.

Sand blasting or wire brushing to a standard of ST 2 is required.

Revised

May-2010

	SARV COAT 8732-8
Epoxy high build multipurpose COATINGS


Description Sarv coat 8732-8 is a two component polyamide cured, high build Multipurpose epoxy coating.	Physical Data Finish............................................... Semi gloss Colour............................................. Upon request Volume Solids............................... 58% (ASTM-D-2699) Specific Gravity............................ 1.50 kg/l Flash Point..................................... 24°C Recommended D.F.T................... 100 microns/ per coat Theoretical coverage.................... 5.8 m²/lat 100 microns Practical Coverage....................... Depends on loss factor Touch dry....................................... 1 hrs at 20°C Fully cured..................................... Seven days 20°C Thermal Resistance...................... 140 °C Shelf life......................................... 1 year at 25°C Application Details Application method .................... Air/airless spray, Brush Nozzle orifice................................. .018”-.021” Nozzle pressure............................. 250 bar/3600 Psi Application temperature............. 10-50 °C Mixing ratio................................... 5(A)+1(B) Thinner/Cleaner............................ SVT-87 Pot life ............................................ 8 hrs at 20°C
Outstanding Characteristics Excellent oil resistance. Excellent chemical resistance against weak acids and alkalies. Resistance to transit and handling damages Corrosion resistance in moderately to severely marine & industrial environment. Adheres to a variety of substrates such as steel, Aluminum, stainless steel, concrete.
Recommended Use As a high build, high performance protective coating in aggressive environment over metal substrate of ships brges, Tank & structural steel in chemical plants refineries. Offshore platforms, sea water.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. (For maintenacce) Abrasive blasting to Sa 2½ , SSPC-10 with a sharp-edged surface profile corresponding to rugotest No.3, BN9a, keane – Tator comparator, 2.0 G/S or ISO comparator, medium(G). (For new steel)

	SARV COAT 8732-9
Epoxy polyamide high solid COATINGS


Description Sarv coat 8732-9 is a two component polyamide cured, high solid epoxy coating.	Physical Data Finish............................................... Semi gloss-gloss Colour............................................. Upon request Volume Solids............................... 45% (ASTM-D-2699 modifed) Specific Gravity............................ 1.16 kg/l Flash Point..................................... 24°C Recommended D.F.T................... 100-150 microns Theoretical coverage.................... 6.5-4.33 sqm/lit 4.64-3.09 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 1 hrs at 20°C 2 hrs at 35 °C Fully cured..................................... 7 days 20°C 6 days at 35°C Thermal Resistance...................... 140 °C Shelf life......................................... 1 year at 25°C Package.......................................... 4&20 liter container Application Details Air/Airless method, ...................... Air/Application spray, Brush Nozzle orifice................................. .018”-.021” Nozzle pressure............................. 250 bar/3600 Psi Mixing ratio................................... Base/Hardener 5/1 by weight Thinner/Cleaner............................ SVT-87 Pot life ............................................ 8 hrs at 20°C
Outstanding Characteristics Excellent oil resistance. Excellent chemical resistance against weak acids and alkalies. Resistance to transit and handling damages Corrosion resistance in moderately to severely marine & industrial environment.
Recommended Use As a high solid, high performance protective coating in aggressive environment over concrete or metal surfaces.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. (For maintenacce) Abrasive blasting to Sa 2½, SSPC-10 with a sharp-edged surface profile corresponding to rugotest No.3, BN9a, keane – Tator comparator, 2.0 G/S or ISO comparator, medium(G). (For new steel)

	SARV COAT 8733
Epoxy polyamide top coat COATINGS


Description Sarv coat 8733 is a two component, polyamide cured epoxy topcoat.	Physical Data Finish............................................... Gloss-Semi gloss Colour............................................. Upon request Volume Solids............................... 52%(ASTM-D-2697) Specific Gravity............................ 1.33 kg/L Flash Point..................................... Not applicable packaging Recommended D.F.T................... 50 microns Theoretical coverage.................... 10.4 m²/lit Practical Coverage....................... Depends on loss factor Touch dry....................................... 180 min 20°C 2 hrs at 35°C Fully cured..................................... 7 days at 20°C 1 week at 35°C Thermal Resistance...................... 140 °C Shelf life......................................... 1 year at 25°C Package.......................................... 5 & 20 liter container Application Details Application method .................... Air/Application spray, Brush Nozzle orifice................................. . .021” Nozzle pressure............................. 150 bar/2200 Psi Mixing ratio................................... Base / Hardener 4/1 by weight Thinner/Cleaner............................ SVT-87 Pot life ............................................ 8 hrs at 20°C Recoat interval min:.................... 24 hrs at 20°C Recoat interval max:................... 14 days at 20°C
Outstanding Characteristics Excellent oil resistance. Excellent chemical resistance against weak acids and alkalies. Suitable as finish coat in various epoxy paint systmes. Corrosion resistance in moderately to severely environment.
Recommended Use As a protective topcoat in industrial and marine structures, over concrete or metal surfaces.
Surface Preparation The surface must be clean and dry, All dirt, grease, mill- scales and any other foreign materials should be removed. Old primed surfaces must be smoothly wire brushed.

	SARV COAT 8734
Epoxy polyamide mio intermdiate COATINGS


Description Sarv coat 8734 is a two component, polyamide cured epoxy coating, containing micaceous iron oxide.	Physical Data Finish............................................... Flat- semi Flat Colour............................................. light grey& Red Volume Solids............................... 53% Specific Gravity............................ 1.40 Flash Point..................................... 30°C Recommended D.F.T................... 50-75 sqm/lit Theoretical coverage.................... 7.6-5 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 2 hrs at 20°C 1 hrs at 35°C Fully cured..................................... Seven days at 20°C 6 days at 35°C Thermal Resistance...................... 140 °C Shelf life......................................... 1 year at 25°C Package.......................................... 5 & 20 liter container Application Details Application method .................... Air/Airless spray, Brush Nozzle orifice................................. .019”-.021” Nozzle pressure............................. 175 bar/2200 Psi Mixing ratio................................... Base/Hardener 4/1/ by weight Thinner/Cleaner............................ SVT- 87 Pot life ............................................ 8 hrs at 20°C
Outstanding Characteristics Suitable for application on blasted steel High abrasion and chemical resistance Good cutting and welding properties Suitable for application under humid condition. Eecellent barrier property.
Recommended Use For protection of structural steel in refineries, mining pulp and paper industries, water sewage plants, bridges, storage tanks and petrochemical plants.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. (For maintenacce) Abrasive blasting to Sa 2½, SSPC-10 with a sharp-edged surface profile corresponding to rugotest No.3, BN9a, keane – Tator comparator, 2.0 G/S or ISO comparator, medium(G). (For new steel)

	SARV COAT 8735
Epoxy polyamide intermdiate COATINGS


Description Sarv coat 8735 is a two component, polyamide cured epoxy intermediate coat.	Physical Data Finish............................................... Semi Flat Colour............................................. Upon request Volume Solids............................... 63% Specific Gravity............................ 1.40 kg/L Flash Point..................................... 30°C Recommended D.F.T................... 125 microns Theoretical coverage.................... 5.0 m²/L at 125 microns Practical Coverage....................... Depends on loss factor Touch dry....................................... 2 hrs at 20°C Fully cured..................................... 7 days at 20°C Thermal Resistance...................... 140 °C Shelf life......................................... 1 year at 25°C Package.......................................... 5 & 20 liter container Application Details Application method .................... Air/Airless spray, Brush Nozzle orifice................................. ..021” Nozzle pressure............................. 150 bar/2200 Psi Mixing ratio................................... Base / Hardener 4/1 by weight Thinner/Cleaner............................ SVT-87 Pot life ............................................ 8 hrs at 20°C Recoat interval min:.................... 24 hrs at 20°C Recoat interval max:................... 14 days at 20°C
Outstanding Characteristics Excellent oil resistance. Excellent chemical resistance against weak acids and alkalies. Suitable as 2nd coat in various epoxy paint systmes. Corrosion resistance in moderately to severely environment.
Recommended Use As a protective intermediate coat in industrial and marine structures, over concrete or metal surfaces.
Surface Preparation The surface must be clean and dry, All dirt, grease, mill- scales and other foreign materials should be removed. Old primed surfaces must be smoothly wire brushed.

SARV COAT 8736

3 pack zinc rich Epoxy primer COATINGS

Description

Sarv coat 8736 is a three component, polyamide cured epoxy primer, containing zinc dust (third component) as corrosion inhibiting pigment.

Physical Data

Finish............................................... Flat

Colour............................................. Grey

Volume Solids............................... 63±2 %

Solid by weight.............................. 90±2%

Zinc content in dry film............... ~91±1% by weight

Specific Gravity............................ 3.1±0.1 gr./cm3

Flash Point..................................... 26°C

Recommended D.F.T................... 50-75 microns

Theoretical coverage.................... 12.6-8.4 m²/L.

4.06-2.70 m²/kg

Practical Coverage....................... Depends on loss factor

Touch dry....................................... 45 min at 20°C

25 min at 35°C

Hard dry......................................... 1 week at 20°C

6 days at 35°C

Thermal Resistance...................... Continuous 180°C

Non-continuous 200°C

Shelf life......................................... 12 months at 20 °C

Package.......................................... 4 & 20 liter container

Application Details

Application method .................... Air/Airless spray Brush

Nozzle orifice................................. . .019" - .021"

Nozzle pressure............................. 150 bar/2200 Psi

Application temperature............. .5-50° C

Mixing ratio................................... Refer to the can label

Thinner/Cleaner SVT- 87

Pot life ............................................ 8 hrs at 20°C

Recoat interval:............................ Min 24 hrs

Max 72 hrs

Outstanding Characteristics

Suitable as prefabrication primer
Good cutting and welding properties
Suitable as a first coat in various paint systems.
Corrosion resistance in moderately to severely environment.

Recommended Use

As a versatile long- life primer on steel, suitable for application on industrial structures to be exposed in severe corrosive atmospheres.

Surface Preparation

Sand blasting or wire brushing a standard of ST 2

(SA 2.5,SIS 05 5900,ISO 8501-1)

Revised

May-2010

SARV COAT 8736-7

2 pack zinc rich Epoxy primer COATINGS

Description

Sarv coat 8736-7 is a two component, polyamide cured epoxy pimer, containing zinc dust as corrosion inhibiting pigment.

Physical Data

Finish............................................... Flat

Colour............................................. Grey

Volume Solids............................... 63±2%

Solid by weight ............................. 90±2

Zinc content in dry film............... ~91±1% by weight

Specific Gravity............................ 3±0.1 gr./cm³

Flash Point..................................... 26°C

Recommended D.F.T................... 50-75 microns

Theoretical coverage.................... 12.6-8.4 m²/Lit

4.2-2.8 m²/kg

Practical Coverage....................... Depends on loss factor

Touch dry....................................... 1-2 hrs at 20°C

Hard dray……………………….1 week at 20°C

Thermal Resistance...................... Continuous 180 °C

Non- Continuous 200 °C

Shelf life......................................... 12 months at 20°C

Package.......................................... 4 & 20 liter container

Application Details

Application method .................... Air/Application spray, Brush

Nozzle orifice................................. . .019" - .021"

Nozzle pressure............................. 150 bar/2200 Psi

Application temperature............. 5-50°C

Mixing ratio................................... Refer to the can label

Thinner/Cleaner............................ SVT-87

Pot life ............................................ 8 hrs at 20°C

Recoat interval min:.................... 24 hrs

Recoat interval max:................... 72 hrs

Outstanding Characteristics

Suitable as prefabrication primer
Good cutting and welding properties
Suitable as a first coat in various paint systems.
High resistance in moderately to severely environment.

Recommended Use

As a versatile long- life primer on steel, suitable for application on industrial structures to be exposed in severe corrosive atmospheres.

Surface Preparation

Sand blasting or wire brushing a standard of ST 2

(SA 2.5,SIS 05 5900,ISO 8501-1).

Revised

May-2010

	SARV COAT 8736-8
2 pack zing rich Epoxy primer COATINGS


Description Sarv coat 8736-8 is a two component, polyamide cured epoxy pimer, containing zinc dust as corrosion inhibiting pigment. The qualiy meets SSSC Panint 20, 1^nd class of zinc rich coating.	Physical Data Finish............................................... Flat Colour............................................. Grey, Red grey Volume Solids............................... 45% (ASTM-D-2697) Specific Gravity............................ 2.15 kg/lit Flash Point..................................... 30°C Recommended D.F.T................... 65 microns Theoretical coverage.................... 6.9 m 2 /l Practical Coverage....................... Depends on loss factor Touch dry....................................... 2-3 hrs at 20°C 1 hrs at 35°C Fully cured..................................... Seven days 20°C 6 days at 35°C Thermal Resistance...................... 140 °C Shelf life......................................... 1 year at 25°C Application Details Application method , .................. Air/Application spray, Brush Nozzle orifice................................. .017”-.021” Nozzle pressure............................. 150 bar/2200 Psi Mixing ratio................................... A/B/ 19/1 by weight Thinner/Cleaner............................ SVT- 87 Pot life ............................................ 8 hrs at 20°C Recoat interval min:.................... 24 hrs at 20°C
Outstanding Characteristics Suitable as prefabrication primer Good cutting and welding properties Suitable as a first coat in various paint systems. High resistance in moderately to severely environment.
Recommended Use As a versatile long- life primer on steel, suitable for application on industrial structures to be exposed in medium corrosive atmospheres.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Abrasive blasting to Sa 2½ , SSPC-10 with a sharp-edged surface profile corresponding to rugotest No.3, BN9a, keane – Tator comparator, 2.0 G/S or ISO comparator, medium(G).

	SARV COAT 8736-9
ZINcA


Description Sarv coat 8736-9 one component zinc copmpound , ready for use with brush , based on aromatic hydrocarbons. ZINCA corresponds to the European standards ISO 3549 – 1987 and DIN 55 969 (zinc concentration in the dry extract of 96 %) and to ISO 752 and DIN 1706 (zinc purity of 99, 995 %)	Physical Data Specific gravity............................. 2.75 ± 0.05 Kg / dm³ Dry extract..................................... 82 % (weight) or 39.8 % (volume) Zinc content in dry extract.......... minimum 95% - 98% (weight) Temperature resistance............... 200 º C (400ºF) +150 / - 40 Viscosity at delivery..................... 3000 to 4600 cps (Brookfield RVT / Spindle # 5 / 100 RPM 20 º C) or DIN / FORD Cup n º 4 : ± 60 sec. Flash point..................................... 47 º C Recommended D.F.T................... 100 – 200 microns Theoretical coverage.................... 1.41 – 0.70 sqm/kg Recommended D.F.T................... 65 microns Colour............................................. metallic grey ( colour changes on contact with humidity ) Packaging....................................... (1,2,5,10 and 25 Kg) (1,5,25 and 200 Lit) Touch dry....................................... 10 min at 15°C Head resistance............................. +150 / 040 Application Details Application method , .................. Air/Application spray, Brush Thinner/Cleaner............................ SVT- 87 Pot life ............................................ 8 hrs at 20°C Recoat interval min:.................... 24 hrs at 20°C
Physical data ZINCA can be applied using most conventional application methods such as brush , roller , airspray – gun and airless spray. Other application methods using aerosols or by dipping are possible.

Surface condition The best cathodic protection with ZINCA will be obtained when blasting to a standard Sa 2.5 with a roughness Rz of approx. 50 µm. (ISO 8501-1 : 1998). In some cases a hand cleaning to a standard St 2 can be sufficient. All surfaces must be prepared to the ISO 8501 -1standard . Application temperature must be above 5 º C and the difference between surface temperature and dew point greater than 3 º C . For specific recommendations .contact your Zingametall representative.

	SARV COAT 8737
Epoxy polyamide zing phosphate primer COATINGS


Description Sarv coat 8737 is a tow component, polyamide cured epoxy primer, containing zinc phoshphate as corrosion inhibiting pigment.	Physical Data Finish............................................... Flat Colour............................................. Yellow, Grey, Green Volume Solids............................... 55% (ASTM-D-2697 modifid) Specific Gravity............................ 1.33 kg/L Flash Point..................................... 25°C Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 13.3-8.8 sqm/lit. 10.2-6.8 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 3 hrs at 20°C 2 hrs at 35°C Fully cured..................................... seven days at 20 °C 6 doys at 35 °C Thermal Resistance...................... 140 °C Shelf life......................................... 1 year at 20°C Package.......................................... 5 & 20 liter container Application Details Application method..................... Air/Airless spray, Brush Nozzle orifice................................. .021" Nozzle pressure............................. 150 bar/2200 Psi Mixing ratio................................... Base/Hardener 4/1 by weight Thinner/Cleaner............................ SVT 87 Pot life ............................................ 8 hrs at 20°C Recoat interval min:.................... 24 hrs at 20°C Recoat interval max:................... 14 days at 20 °C
Outstanding Characteristics Suitable for application on blasted Good cutting and welding properties Suitable as a first coat in various paint systems. Suitable for application under humid condition.
Recommended Use As a general purpose rust preventing primer for epoxy and urethane systems on steel and other metal surfaces.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Clean damaged area thoroughly by power tool cleaning to ST3 (minor areas) Or by abrasive blasting to minimum SA2, Preferably to Sa2½ (for repair and maintenance) Abrasive blasting to Sa 2½SSPC-10 (for new steel).

	SARV COAT 8738
Epoxy polyamide zinc chromate primer COATINGS


Description Sarv coat 8738 is a two component polyamide cured epoxy primer containing zinc chromate as corrosion inhibiting pigment .	Physical Data Finish............................................... Flat Colour............................................. light yellow, green Volume Solids............................... 53% Specific Gravity............................ 1.3±0.05 gr/cm³ Flash Point..................................... 26°C Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 13.3-8.8 sqm/lit. 10.2-6.8 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 3 hrs at 20°C 2 hrs at 35°C Fully cured..................................... seven days at 20°C 6 days at 35°C Thermal Resistance...................... 140 °C Shelf life......................................... 1 year at 25°C Package.......................................... 5 & 20 liter container Application Details Application method..................... Air/Airless spray, Brush Nozzle orifice................................. . .021" Nozzle pressure............................. 150 bar/2200 Psi Mixing ratio................................... Base/Hardener 4/1 by weight Thinner/Cleaner............................ SVT- 87 Pot life ............................................ 8 hrs at 20°C Recoat interval min:.................... 24 hrs at 20°C Recoat interval max:................... 14 days at 20 °C
Outstanding Characteristics Suitable for application on blasted steel. Good cutting and welding properties Suitable as a first coat in various paint systems. Suitable for use in industrial & marine environment
Recommended Use As a general purpose rust preventing primer for epoxy and urethane systems on steel and other metal surfaces.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Clean damaged area thoroughly by power tool cleaning to ST3 (minor areas) Or by abrasive blasting to minimum SA2, Preferably to Sa2½ (for repair and maintenance) Abrasive blasting to Sa 2½SSPC-10 (for new steel).

	SARV COAT 8739
Epoxy polyamide red oxide primer COATINGS


Description Sarv coat 8739 is a two component polyamide cured epoxy primer containing red oxide as corrosion inhibiting pigment.	Physical Data Finish............................................... Flat Colour............................................. Red Volume Solids............................... 51%±2 Specific Gravity............................ 1.35±0.05 gr/cm³ Flash Point..................................... 26°C Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 12.8-8.5 sqm/lit. 9.5-6.3 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 2 hrs at 20°C 6 days at 35°C Fully cured..................................... seven days at 20°C 6 days at 35°C Thermal Resistance...................... 140 °C Shelf life......................................... 1 year at 20°C Package.......................................... 5 & 20 liter container Application Details Application method..................... Air/Airless spray, Brush Nozzle orifice................................. . .021" Nozzle pressure............................. 150 bar/2200 Psi Mixing ratio................................... single pack Thinner/Cleaner............................ SVT-87 Pot life ............................................ 8 hrs at 20°C Recoat interval min:.................... 24 hrs at 20°C Recoat interval max:................... 14 days at 20 °C
Outstanding Characteristics Excellent rust preventing High chemical & water resistance Suitable as a first coat in various paint systems. Suitable for a variety of substances
Recommended Use As a general purpose rust preventing primer for epoxy systems, on steel and other metal surfaces, even primed with sarv coat 1983.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Clean damaged area thoroughly by power tool cleaning to ST3 (minor areas) Or by abrasive blasting to minimum SA2, Preferably to Sa2 (for repair and maintenance) Abrasive blasting to Sa 2½SSPC-10 (for new steel).

	SARV COAT 8740
Epoxy polyamide primer COATINGS


Description Sarv coat 8740 is a two component polyamide cured epoxy primer or tie coat.	Physical Data Finish............................................... Flat Colour............................................. upon request Volume Solids............................... 51%(ASTM-D-2697 modified) Specific Gravity............................ 1.30±0.05 gr/cm³ Flash Point..................................... 30°C Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 12.75-8.5 sqm/lit. 9.44-6.3 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 2 hrs at 35°C 3 hrs at 20°C Fully dry......................................... seven days at 20°C 6 days at 35°C Thermal Resistance...................... 140°C Shelf life ........................................ 1 year at 25°C Package.......................................... 5 & 20 liter container Application Details Application method .................... Application method Brush, Roller. Nozzle orifice................................. . .021" Nozzle pressure............................. 150 bar/2200 Psi Mixing ratio................................... Base/Hardener 4/1 by weight Thinner/Cleaner............................ SVT- 87 Pot life ............................................ 8 hrs at 20°C Recoat interval min:.................... 24 hrs at 20°C Recoat interval max:................... 14 days at 20° C
Outstanding Characteristics Excellent rust preventing High chemical & water resistance Suitable as a first coat in various paint systems. Suitable for a variety of substances. with the proper top coat, withstand splash or spillage of water, solvents, chemicals and petroleum products.
Recommended Use As a general purpose rust preventing primer for epoxy systems, on structural steel, galvanized surfaces, pipes, tanks oil refineries, power plants. Chemical process plants, for immersion and non immersion service, applicable both as primer & tie coat over zinc ethyl silicate.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Clean damaged area thoroughly by power tool cleaning to ST3 (minor areas) Or by abrasive blasting to minimum SA2, Preferably to Sa2½ (for repair and maintenance) Abrasive blasting to Sa 2½SSPC-10 (for new steel).

	SARV COAT 8819
Epoxy polyamine solvent free clear COATINGS


Description Sarv coat 8819 is a two component, polyamine cured, solvent free transparent epoxy coat.	Physical Data Finish............................................... Gloss Colour............................................. Transparent Volume Solids............................... 100% Specific Gravity............................ 1.11±0.02 gr/cm³ Flash Point..................................... 100°C Recommended D.F.T................... 100-200 microns Theoretical Coverage................... 10-5 sqm/lit 9-4.5 sqm/kg Practical Coverage....................... depends on loss factor Touch dry....................................... 8 hrs at 20°C 5 hrs at 35°C Hard dry......................................... 1 week at 35°C Thermal Resistance...................... 140°C Shelf life ........................................ 1 year Application Details Application method .................... Air/Airless Spray Brush, Roller Nozzle orifice................................. .017"- .021" Nozzle pressure............................. 100 bar/1450 Psi Application temperature............. 10-50°C Mixing ratio................................... Base/Hardener/2/1 by weight Cleaner........................................... SVT-88 Pot life ............................................ 30 min at 20°C Recoat interval.............................. Min 16 hrs at 20°C Max 72 hrs at 20°C
Outstanding Characteristics Excellent mechanical strength High oil resistance High chemical resistance against acids, alkalis & selvents. No toxicity. Applicable in high film thickness.
Recommended Use As a transparent epoxy topcoat on epoxy paint systems where a high glossy finish is required or for topcoating of epoxy systems for coating potable water tanks.
Surface Preparation The surface must be clean & dry All dirt, grease, mill-scales and any other foreign materials should be removed.

	SARV COAT 8820
Epoxy polyamine solvent free sealer COATINGS


Description Sarv coat 8820 is a two component, polyamine cured, solvent free epoxy primer& sealer with good penetration properties.	Physical Data Finish............................................... Glossy Colour............................................. Transparent Volume Solids............................... 99±1% Specific Gravity............................ 1.45±0.05 gr/cm³ Flash Point..................................... 65°C Dry Film Thickness....................... Depending on surface porosity Touch dry....................................... 4 hrs at 20°C 5 hrs 35°C Hard dry......................................... 1 week at 20°C 5 days at 35°C Thermal Resistance...................... 140°C Theoretical Coverage................... depends on D.F.T Practical Coverage....................... depends on loss factor Shelf life ........................................ 1 year Package.......................................... 5& 20 liter container Application Details Application method .................... Air/Airless spray Brush, Roller Nozzle orifice................................. .021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°C Base/Hardener Mixing ratio................................... 4/1 by weight Thimer/ Cleaner............................ SVT-88 Pot life ............................................ 40 min at 20°C Recoat interval.............................. Min 16 hrs Max 72 hrs
Outstanding Characteristics Excellent mechanical strength High oil resistance High chemical resistance against weak acids and alkalies. Easy application.
Recommended Use As a sealer for pretreatment of concrete floors, prior to application of epoxy flooring & as a primer in epoxy coating systems.
Surface Preparation The surface must be clean & dry All dirt, grease, mill-scales and any other foreign materials should be removed. The concrete substrate should be old at least 28 days. The maximum moisture content is 0.6%

	SARV COAT 8821
Epoxy polyamine flooring COATINGS


Description Sarv coat 8821 is a two component, polyamine cured, solvent free epoxy coating.	Physical Data Finish............................................... Gloss Colour............................................. limited Volume Solids............................... 95±2% Specific Gravity............................ 1.45±0.05 gr/cm³ Flash Point..................................... 32°C Dry Film Thickness....................... 1000-3000 microns Theoretical Coverage................... 0.95- 0.31 sqm/lit 0.65-021 sqm/kg Touch dry....................................... 8 hrs at 20°C Hard dry......................................... 48 hrs at 20°C Thermal Resistance...................... 140°C Shelf life ........................................ 1 year at 25 °C Package.......................................... 4 & 20 liter container Application Details Application method .................... Putty Knife, Trowel Application temperature............. 10-50°C Mixing ratio................................... 5/ 1 by weight Pot life ............................................ 60 min at 20°C Recoat interval.............................. Min 8 hrs Max 72 hrs
Outstanding Characteristics Excellent mechanical strength High oil resistance High chemical resistance against weak acids and alkalis. Easy application.
Recommended Use As a suitable floor coating on concrete or steel industrial floors subjected to continuous mechanical wear and where chemical and solvents resistance is required.
Surface Preparation The surface must be clean and dry. All dirt, grease, mill-scales and any other foreign materials should be removed. Mechanical characteristics (For3 mm film thickness) Compressive strength (BS6319 pt3) 50 N/mm² Flexural strength (BS6319 pt7) 34 N/mm² Foot traffic at 20°C 24 hrs Vehicle traffic at 20°C 48 hrs

	SARV COAT 8821-7
Epoxy polyamine anti-acid floor COATINGS


Description Sarv coat 8821-7 is a two component, polyamine cured, solvent free epoxy Anti-Acid floor coating.	Physical Data Finish............................................... Gloss Colour............................................. limited Volume Solids............................... 94±2% Specific Gravity............................ 1.48±0.05 gr/cm³ Flash Point..................................... 32°C Dry Film Thickness....................... 1000-3000 microns Theoretical Coverage................... 0.94- 0.31 sqm/lit 0.63-0.20 sqm/kg Touch dry....................................... 8 hrs at 20°C Hard dry......................................... 48 hrs at 20°C Thermal Resistance...................... 140°C Shelf life ........................................ 1 year at 25°C Application Details Application method .................... Putty Knife, Trowel Application temperature............. 10-50°C Mixing ratio................................... 6/ 1 by weight Pot life ............................................ 60 min at 20°C Recoat interval.............................. Min 8 hrs Max 72 hrs
Outstanding Characteristics Excellent mechanical strength High oil resistance High chemical resistance against acids and alkalies. Easy application. High electrical conductivity
Recommended Use As a suitable floor coating on concrete or steel industrial floors subjected to continuous mechanical wear and where, acid, chemical solvents resistance is required.
Surface Preparation The surface must be clean and dry. All dirt, grease, mill-scales and any other foreign materials should be removed. Mechanical characteristics (For3 mm film thickness) Compressive strength (BS6319 pt3) 50 N/mm² Flexural strength (BS6319 pt7) 34 N/mm² Foot traffic at 20°C 24 hrs Vehicle traffic at 20°C 48 hrs

	SARV COAT 8821-8
Epoxy polyamine anti-staic flooring COATINGS


Description Sarv coat 8821-8 is a two component, polyamine cured, solvent free epoxy Anti-static floor coating.	Physical Data Finish............................................... Gloss Colour............................................. Grey Volume Solids............................... 97±2% Specific Gravity............................ 1.35±0.05 gr/cm³ Flash Point..................................... 23°C Dry Film Thickness....................... 3000-5000 microns Theoretical Coverage................... 0.19- 0.32 sqm/lit 0.14-0.23 sqm/kg Touch dry....................................... 8 hrs at 20°C The electrical resistance…...........10-1000(ohm) Hard dry......................................... 2 days at 20°C Thermal Resistance...................... 140°C Shelf life ........................................ 1 year at 25°C Package.......................................... 5& 20 liter container Application Details Application method .................... Putty Knife, Trowel Application temperature............. 10-50°C Mixing ratio................................... Base /Hardener 4/ 1 by weight Pot life ............................................ 60 min at 20°C Recoat interval.............................. Min 8 hrs Max 72 hrs
Outstanding Characteristics Excellent mechanical strength High oil resistance High chemical resistance against weak acids and alkalies. Easy application. High electrical conductivity
Recommended Use As a suitable floor coating on concrete or steel industrial floors subjected to continuous mechanical wear and where electric conductivity and chemical & solvents resistance is required.
Surface Preparation The surface must be clean and dry. All dirt, grease, mill-scales and any other foreign materials should be removed. Mechanical characteristics (For3 mm film thickness) Compressive strength (BS6319 pt3) 50 N/mm² Flexural strength (BS6319 pt7) 34 N/mm² Foot traffic at 20°C 24 hrs Vehicle traffic at 20°C 48 hrs E lectric conductivity 10⁶ ohm/cm

	SARV COAT 8822-7
Epoxy Fiberclass COATINGS


Description Sarv coat 8822-7 is a tow component, polyamine cured, solvent free transparent epoxy. The epoxy fiberglass coating for the tank bottom consists of the sarv coat 8822-7 epoxy coating with one or two layers of the chopped strand glassmat plus one layer of the surfacing tissue.	Physical Data Finish............................................... Gloss Colour............................................. Clear Substrate........................................ steel or steel primed with sarv coat 8820 Volume Solids............................... 100 % Specific Gravity............................ 1.1±0.02 gr/cm³ Flash Point..................................... 65°C Recommended D.F.T................... 2.5 mm Theoretical coverage Epoxy............................................. 2.5 litre/sqm Fiberglass mat............................... 450 gram/sqm Fiberglass tissues........................... 30 gram/ sqm Practical Coverage....................... Depends on loss factor Silica sand particle size................ 0.1-0.3 mm Curring time (at 20° C) To recoat........................................ up to 2 days Initial set......................................... 24 hrs Full chemical resistance............... 9 days Thermal Resistance...................... immersed :95°C Non-immersed: 120 °C Shelf life ........................................ 1 year package ......................................... 4 liter container Application Details Application method .................... spray or Roller Base/Hardener Mixing ratio................................... 2/ 1 by weight Cleaner........................................... SVT- 88 Pot life(20°C) .............................. 1.5 hrs for 10 litre
Outstanding Characteristics Sarv coat 8822-7 epoxy laminate system will provide corrosion and chemical resistance to bottoms of water or oil storage tanks, which have suffered from internal corrosion. Sarv coat 8840-7 is specifically resistant to the corrosive environment of crude oil/ water mixtures. It provides great strength and excellent chemical resistance.
Typical Use Sarv coat 8822-7 Epoxy laminate system is specifically designed for the lining and/or repair of tank walls and tank bottoms of oil or water storage tanks which are corroded and pitted.
Theoretical Consumptin per m² Sarv coat 8820 primer (tie coat) 0.14 litre Sarv coat 8822-7 filler (surfacer /filler) 380 grams Sarv coat 8822-7 epoxy for sufacer/filler 0.16 litre Sarv coat 8822-7 lining 2.5 litre when using the 450 g/m² glassmat a 10% overlap is necessary resulting in a consumption of 1.1 m² glassmat per m² when using the 300 g/m² glassmat a 50% overlap is necessary resulting in a consumption of 2 m² per m² NOTE: A ctual consumption per m² depends on tank design and steel condition. For instance heavily pitted areas, steel plate overlaps striker pads and chime areas influence the practical consumption rate.

	SARV COAT 8823
Epoxy polyamine solvent free COATINGS


Description Sarv coat 8823 is a two component, polyamine cured, solvent free epoxy coating.	Physical Data Finish............................................... Gloss, Semi glass Colour............................................. upon request Volume Solids............................... %100 Specific Gravity............................ 1.45 kg/L Flash Point..................................... 60°C Touch dry....................................... 24 hrs at 20°C Hard dry......................................... 1 week at 20°C Recommended DFT..................... 150-500 mic Thermal Resistance...................... 140°C Theoretical Coverage................... 250 g/m² 500 g/m² Practical Coverage....................... Depends on loss factor Shelf life ........................................ 1 year at 25°C Package.......................................... 4&20 liter container Application Details Application method .................... Airless spray Nozzle orifice................................. . .019"-.031" Nozzle pressure............................. 250 bar/3600 Psi Application temperature............. 5-50°C Mixing ratio................................... Base/Hardener 5/ 1by weight Thinner/Cleaner............................ SVT-88 Pot life ............................................ 1 hrs at 20°C Recoat interval.............................. Min 24 hrs Max 72 hrs
Outstanding Characteristics Excellent mechanical strength High oil resistance High chemical resistance against weak acids and alkalis. Applicable in high film thickness.
Recommended Use As a solvent free epoxy coating with excellent chemical & mechanical properties, suitable for coating chemical products containers and industrial or marine structures.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning.(For maintenance) Abrasive blasting to Sa 2½ SSPC-10 with a sharp –edged surface profile corresponding to Rugotest No.3, BN9a, Keane- Tator comparator, 2.0 G/S or ISO comparator, medium (G). (For new steel)

	SARV COAT 8824
Epoxy polyamine glass flake COATINGS


Description Sarv coat 8824 is a two component, polyamine cured, high build glass flake epoxy coating.	Physical Data Finish............................................... Semi gloss Colour............................................. limited Volume Solids............................... 68 ± 2 % Weight solied ................................ 80 ± 2 Specific Gravity............................ 1.3±0.05 gr/cm³ (Mixed) Flash Point (closed cup)............... 32°C Touch dry....................................... 10 hrs at 20°C Hard dry......................................... 1 week at 20°C Dry film thickness......................... 300 micnons Theoretical coverage.................... 2.36 sqm/lit 1.74 sqm/kg Practical Coverage....................... Depends on loss factor Shelf life ........................................ 1 year at 25°C Application Details Application method .................... Airless 1:60 (See Remark over leaf) Nozzle orifice................................. . .035"-.045" reversible Nozzle pressure............................. 250 bar/3600 Psi Mixing ratio................................... Base/Hardener 6/ 1 by weight Thinner/Cleaner............................ SVT-88 Pot life ............................................ 1 hrs at 20°C
Outstanding Characteristics Excellent mechanical strength High resistance against crude oil. High chemical resistance against weak acids and alkalies. Applicable in high film thickness. High sea water resistance or use in splash and tidal zone.
Recommended Use As a epoxy coating with excellent chemical & mechanical properties, suitable for coating chemical products containers and industrial or marine structures. It protects both steel and concrete structures in severe environments including marine structures petroleum and heavy industrial facilities.
Surface Preparation Remove and oil, grease and other, other contaminants by detergent and salt high pressure fresh water hosing prior to water hosing prior to abrasive blasting. Abrasive blasting to Sa2½ ( ISO 8501-1:1988) with a surface propfile equivalent to regotes No. 3 BN 10b, Keane- tator comprator 3.0 G/S ISO comprator, rough Medium. (G)

	SARV COAT 8824-6
epoxy polyamine glass flake COATINGS


Description Sarv coat 8824-6 is a two component, polyamine cured, solvent free glass flake epoxy coating.	Physical Data Finish............................................... Semi Gloss Colour............................................. limited Volume Solids............................... 91 %(ASDM-D 2697) modified Specific Gravity............................ 1.5 kg /L Flash Point(closed cud)................ 30°C Touch dry....................................... 6 hrs at 20°C Hard dry......................................... 1 week at 20°C Dry film thickness......................... 200-750 microns Thermal coverage......................... 4.2 m²/L at 200 microns 1.2 m²/L at 750 microns Practical Coverage....................... Depends on loss factor Shelf life ........................................ 1 year at 25°C Application Details Application method .................... Airless 1:63 (see Remark over leaf) Nozzle orifice................................. 0.035"-0.050" Nozzle pressure............................. 250 bar/3600 Psi Mixing ratio................................... Base/ Hardener 4/1 by weight Thinner/Cleaner............................ SVT 88 Pot life ............................................ 1 hrs at 20°C
Outstanding Characteristics Excellent mechanical strength. High resistance against crude oil. High chemical resistance against weak acids and alkalies. Applicable in high film thickness. High sea water resistance or use splash and tidal zone.
Recommended Use As a epoxy coating with excellent chemical & mechanical properties, suitable for coating chemical products containers and industrial or marine structures. It protects both steel and concrete structures in severe environments including marine structures petroleum and heavy industrial facilities.
Surface Preparation Remove any oil, grease and other contaminants by detergent and salt high pressure fresh water hosing prior to abrasive blasting. Abrasive blasting to Sa2 ½(ISO 8501-1:1988) with a surface equivalent to regotest No.3 BN 10b, Keane-tator comprator 3.0 G/S ISO comprator rough Medium.(G)

	SARV COAT 8824-7
Epoxy polyamine high build abrasion resistant COATINGS


Description Sarv coat 8824-7 is a two component, polyamine cured, high build epoxy coating silicium oxide as reinforcing ingredient.	Physical Data Finish............................................... Flat Colour............................................. Upon request Volume Solids............................... 85 %(ASDM-D 2697) Specific Gravity............................ 1.31 kg/L Flash Point..................................... 30°C Reconnended D.F.T ................... 150 microns /percoat Thermal coverage......................... 6.8 m²/L Practical Coverage....................... Depends on loss factor Touch dry....................................... 6 hrs at 20°C Hard dry......................................... 7 days at 20°C Thermal Resistance...................... 140°C Shelf life ........................................ 1 year at 25°C Application Details Application method .................... Air/Airless Spray Bursh Nozzle orifice................................. .021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 5-50°C Thinner/Cleaner............................ SVT-88 Pot life ............................................ 2 hrs at 20°C Recoat interval.............................. Min 24 hrs Max 72 hrs
Outstanding Characteristics Excellent abrasion resistance. Excellent chemical resistance against weak acids and alkalies. Corrosion resistance in moderately to severely marine & industrial environment.
Recommended Use As a high build, high performance protective coating in aggressive environment over concrete or metal surfaces where a non skid & abrasion resistant surface is needed.
Surface Preparation The surface must be clean and dry. All dirt, grease, mill- scales and any other foreign materials should be removed.

	SARV COAT 8824 -9
Epoxy polyamine glass flake COATINGS


Description Sarv coat 8824-9 is a two component, polyamine cured, high build glass flake epoxy coating.	Physical Data Finish............................................... Semi gloss Colour............................................. limited Volume Solids............................... 87 % (ASDM-D-2697) modified Specific Gravity............................ 1.3-1.5 kg/L Flash Point (closed cup)............... 36°C Touch dry....................................... 6 hrs at 20°C Hard dry......................................... 1 week at 20°C Dry film tickness........................... 125 microns m² perecat Theoretical coverage.................... 7 m²/L at 125 microns Practical Coverage....................... Depends on loss factor Shelf life ........................................ 1 year at 25°C Application Details Application method .................... Airless 1:63 (See Remark over leaf) Nozzle orifice................................. . .035"-.050" Nozzle pressure............................. 250 bar/3600 Psi Mixing ratio................................... Base/Hardener 5/ 1 by weight Thinner/Cleaner............................ SVT-88(Max. ro 15%( Pot life ............................................ 1 hrs at 20°C
Outstanding Characteristics Excellent mechanical strength High resistance against crude oil. High chemical resistance against weak acids and alkalies. Applicable in high film thickness. High sea water resistance or use splash and tidal zone.
Recommended Use As a epoxy coating with excellent chemical & mechanical properties, suitable for coating chemical products containers and industrial or marine structures. It protects both steel and concrete structures in severe environments including marine structures petroleum and heavy industrial facilities.
Surface Preparation Remove and oil, grease and other, contaminants by detergent and salt high pressure fresh water hosing prior to abrasive blasting. Abrasive blasting to Sa2½ ( ISO 8501-1:1988) with asurface proflle equivalent to regotest No. 3 BN 10b, Keane- tator comprator 3.0 G/S ISO comprator, rough Medium. (G)

	SARV COAT 8825
Epoxy polyamine high build COATINGS


Description Sarv coat 8825 is a two component, polyamine cured, high build epoxy coating.	Physical Data Finish............................................... Semi gloss Colour............................................. Upon request Volume Solids............................... 69 % (ASTM-D-2697 modified) Specific Gravity............................ 1.73 kg/L Flash Point..................................... 28°C Recommended D.F.T................... 100-150 microns Theoretical coverage.................... 4.6 m²/L at 100 microns 6.9 m²/L at 150 microns Practical Coverage....................... Depends on loss factor Touch dry....................................... 5 hrs at 20°C Fully cured..................................... 1 week at 20°C Thermal Resistance...................... 140°C Shelf life ........................................ 1 year at 25°C Application Details Application method .................... Air/Airless spray, Bursh Nozzle orifice................................. . .021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°C Mixing ratio................................... Base/Hardener 10/ 1by weight Thinner/Cleaner............................ SVT-88 Pot life ............................................ 2 hrs at 20°C Recoat interval.............................. Min 24 hrs Max 72 hrs
Outstanding Characteristics Excellent oil resistance Excellent chemical resistance against weak acids and alkalies. Resistance to transit and handling dumages. Corrosion resistance in moderately to severely marine & industrial environment.
Recommended Use As a high build, high performance protective coating in aggressive environment over concrete or metal surfaces.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by(high pressure) fresh water cleaning(For maintenance). Abrasive blasting to Sa2 ½, SSPC-10 with a sharp-edged surface profile corresponding to Rugotest No. 3, BN9a, keane-Tator comparator, 2.0 G/S or ISO comparator medium(G). (For new steel)

	SARV COAT 8826
Epoxy polyamine top coat COATINGS


Description Sarv coat 8826 is a two component, amine adduct cured, epoxy topcoat.	Physical Data Finish............................................... Gloss Colour............................................. Upon request Volume Solids............................... 54 % Specific Gravity............................ 1.3±0.05 gr/cm³ Flash Point..................................... 23°C Reconnended D.F.T ................... 50-70 microns Thermal coverage......................... 10.8-7.7 sqm/lit 8.3-5.9 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 2 hrs at 20°C Hard dry......................................... 1 week at 20°C Thermal Resistance...................... 140°C Shelf life ........................................ 1 year at 25°C Application Details Application method .................... Air/Airless Spray Bursh, Roller Nozzle orifice................................. .021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°C Mixing ratio................................... Base / hardener/10/ 1by weight Thinner/Cleaner............................ SVT-88 Pot life ............................................ 2 hrs at 20°C Recoat interval.............................. Min 24 hrs Max 72 hrs
Outstanding Characteristics Excellent mechanical strength. High oil resistance High chemical resistance against acids, alkalies & solvents. No toxicity
Recommended Use As an epoxy topcoat with excellent chemical and mechanical properties, suitable for coating chemical products containers.
Surface Preparation The surface must be clean and dry. All dirt, grease, mill- scales and any other foreign materials should be removed. Old primed surfaces must be smoothly wire brushed.

	SARV COAT 8827
Epoxy polyamine intermediate COATINGS


Description Sarv coat 8827 is a two component, polyamine cured epoxy intermediate coat.	Physical Data Finish............................................... Flat-Semi Gloss Colour............................................. Upon request Volume Solids............................... 57 % Specific Gravity............................ 1.35±0.05 gr/cm³ Flash Point..................................... 23°C Reconnended D.F.T ................... 50-70 microns Thermal coverage......................... 11.4-8.1 sqm/lit 8.4-6 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 2 hrs at 20°C Hard dry......................................... 1 week at 20°C Thermal Resistance...................... 140°C Shelf life ........................................ 1 year at 25°C Application Details Application method .................... Air/Airless Spray Bursh, Roller Nozzle orifice................................. .021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°C Mixing ratio................................... Base / hardener/10/ 1by weight Thinner/Cleaner............................ SVT-88 Pot life ............................................ 2 hrs at 20°C Recoat interval.............................. Min 24 hrs Max 72 hrs
Outstanding Characteristics Excellent mechanical strength. High oil resistance High chemical resistance against acids, alkalies & solvents. No toxicity
Recommended Use As an intermediate epoxy coating with excellent chemical and mechanical products containers.
Surface Preparation The surface must be clean and dry. All dirt, grease, mill- scales and any other foreign materials should be removed. Old primed surfaces must be smoothly wire brushed.

	SARV COAT 8828-8
Epoxy polyamine anti-static primer COATINGS


Description Sarv coat 8828-8 is a two component, polyamine cured epoxy anti static primer.	Physical Data Finish............................................... Semi Gloss Colour............................................. Black Volume Solids............................... 65 % Specific Gravity............................ 1.20±0.05 gr/cm³ Flash Point..................................... 30°C Dry Film Thickness ..................... 40-60 microns Touch dry....................................... 2 hrs at 20°C Hard dry......................................... 1 week at 20°C Thermal Resistance...................... 140°C Thermal coverage......................... 17.25-11.5 sqm/lit ......................................................... 13.8-9.25 sqm/kg Practical Coverage....................... Depends on loss factor Shelf life ........................................ 1 year at 25°C Application Details Application method .................... Bursh, Trowel Application temperature............. 10-50°C Mixing ratio................................... Base / hardener/5/ 1by weight Thinner/Cleaner............................ SVT-88 Pot life ............................................ 90 min at 20°C Recoat interval.............................. Min 24 at 20°C Max 72 hrs at 20°C
Outstanding Characteristics Excellent mechanical strength. High chemical & solvent resistance High electrical conductivity Easy application
Recommended Use As a primer coat on concrete, floors subjected to electrical conductivity.
Surface Preparation The surface must be clean & dry. All dirt, Grease, mill scales and any other foreign materials should be removed.

	SARV COAT 8829
Epoxy polyamine zing phosphate primer COATINGS


Description Sarv coat 8829 is a two component, polyamine cured epoxy primer, containing zinc phosphate as corrosion inhibiting pigment.	Physical Data Finish............................................... Flat- Semi flat Colour............................................. Grey, white Volume Solids............................... 54% Specific Gravity............................ 1.30±0.05 gr/cm³ Flash Point..................................... 26°C Dry Film Thickness....................... 40-60 microns Theoretical coverage.................... 13.5-9 sqm/lit. 10.34-6.9 sqm/kg Touch dry....................................... 2 hrs at 20°C Hard dry......................................... 7 days at 20°C Thermal Resistance...................... 140°C Practical Coverage....................... depends on loss factor Shelf life ........................................ 1 year at 25°C Application Details Application method .................... Air/Airless spray, Bursh Nozzle orifice................................. . .021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°C Mixing ratio................................... Base/Hardener 10/ 1by weight Thinner/Cleaner............................ SVT- 88 Pot life ............................................ 2 hrs at 20°C Recoat interval.............................. Min 24 hrs Max 72 hrs
Outstanding Characteristics Suitable for application on blasted steel Suitable as first coat in various paint systems Suitable for application under humid condition. Suitable for water immersion.
Recommended Use As a general purpose rust preventing primer for epoxy and urethane systems on steel and other metal surfaces.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by (high pressure) fresh water cleaning. Clean damaged area thoroughly by power tool cleaning to ST3(minor areas) Or by abrasive blasting to minimum SA2, Preferably to SA2½ (for repair and maintenance) Abrasive blasting to Sa 2½ SSPC-10 (for new steel)

	SARV COAT 8829-7
surface tolerant Epoxy mastics COATINGS


Description Surface tolerant zinc phosphate epoxy mastic is a high solids, high build, fast drying, polyamine epoxy designed to protect steel and concrete in industrial exposures, ideal for maintenance painting and fabrication shop applications. The high solids content ensures adequate protection of sharp edges, corners, and welds.	Physical Data Finish............................................... Gloss Colour............................................. Grey, Red oxide Volume Solids............................... 80 % Weigh solid..................................... 90% ± 2% mixed Specific Gravity............................ 1.45±0.05 gr/cm³ Flash Point..................................... 30°C Recommended D.F.T................... 100-200 microns Practical Coverage....................... Depends on loss factor Touch dry....................................... 2 hrs at 25°C Through dry................................... 4.30 hours at 25°C Hard dry......................................... 1 week at 25°C Thermal Resistance...................... 140°C Shelf life ........................................ 1 year at 25°C Package.......................................... 20/4 liter conatainer Application Details Application method .................... Air/Airless spray, Bursh Application temperature............. 5-50°C Mixing ratio................................... 5 base / 1 hardener Thinner/Cleaner............................ SVT-88 Pot life ............................................ 1.0 hours Recoat interval.............................. Min 2 hours at 20°C Max 72 hrs at 20°C
Outstanding Characteristics Low VOC Film build on sharp edges and corners Chemical resistant Abrasion resistant
Recommended Use For use over prepared steel and concrete in industrial exposures such as: Fabrication shops - Refineries Pulp and paper mills - Chemical plants Power plants - Tank Exteriors Offshore Platforms - Water treatment Plants Marine application - Concrete floors
Surface Preparation The surface must be clean. Dry and free of grease, mill scales and dirt. This product can be applied directly to marginally prepared steel surfaces.

	SARV COAT 8830
Epoxy polyamine zinc chromate primer COATINGS


Description Sarv coat 8830 is a two component, polyamine cured epoxy primer, containing zinc chromate as corrosion inhibiting pipment.	Physical Data Finish............................................... Flat- Semi flat Colour............................................. light yellw, Green Volume Solids............................... 54% Specific Gravity............................ 1.35±0.05 gr/cm³ Flash Point..................................... 26°C Recommended D.F.T................... 40-60 microns Theoretical coverage.................... 13.5-9 sqm/lit. 10-67 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 2 hrs at 20°C Fully cured..................................... 1 week at 20°C Thermal Resistance...................... 140°C Shelf life ........................................ 1 year at 25°C Application Details Application method .................... Air/Airless spray, Bursh Nozzle orifice................................. . .021" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10-50°C Mixing ratio................................... Base/Hardener 10/ 1by weight Thinner/Cleaner............................ SVT-88 Pot life ............................................ 2 hrs at 20°C Recoat interval.............................. Min 24 hrs Max 72 hrs
Outstanding Characteristics Suitable for application on blasted steel Good cutting and welding properties Good resistance against acids & alkalies. Suitable for use in industrial & marine environment
Recommended Use As a highly rust preventing primer for epoxy and urethane systems on steel and other metal surfaces in highly corrosive industrial & marine atmospheres.
Surface Preparation Remove oil and grease, etc. with suitable detergent. Remove salt and other contaminants by(high pressure) fresh water cleaning. Clean damaged area thoroughly by power tool cleaning to ST3(minor areas) Or by abrasive blasting to minimum SA2, Preferably to SA2½ (for repair and maintenance) Abrasive blasting to Sa 2½ SSPC-10 (for new steel)

	SARV COAT 8831
Epoxy polyamine putty COATINGS


Description Sarv coat 8831 is a two component, polyamine cured, solvent free epoxy putty.	Physical Data Colour............................................. upon request Volume Solids............................... 99±1% Specific Gravity............................ 1.85±0.05 gr/cm³ Flash Point..................................... 65°C Touch dry....................................... 5 hrs at 20°C Hard dry......................................... 1 week at 20°C Thermal Resistance...................... 140°C Shelf life ........................................ 1 year Package.......................................... 20& 20 liter container Application Details Application method .................... knife Application temperature............. 5-50°C Mixing ratio................................... 1/1 by weight Thinner/Cleaner............................ SVT-88 Pot life ............................................ 1 hrs at 20°C Recoat interval.............................. Min 24 hrs Max 72 hrs
Outstanding Characteristics Excellent mechanical strength High oil resistance High chemical resistance against acids and alkalis. Applicable in high film thickness.
Recommended Use As a solvent free epoxy coating with excellent chemical & mechanical properties, suitable for coating chemical products containers and industrial or marine structures.
Surface Preparation The surface must be clean and dry. All dirt, grease, millscales and any other foreign materials should be removed.

	SARV COAT 8968
Epoxy phenolic top coat COATINGS


Description Sarv coat 8968 is a two component, polyamine cured epoxy phenolic.	Physical Data Finish............................................... Glossy Colour............................................. Upon request Volume Solids............................... 65±2% Specific Gravity............................ 1.4±0.05 gr/cm³ Flash Point..................................... 26°C Recommended D.F.T................... 100-150 microns Theoretical Coverage................... 6.5-4.3 sqm/lit 4.6-3.07 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 4 hrs at 20°C Hard dry......................................... 7 days at 20°C 6 days at 35°C Thermal Resistance...................... Continuous 160°C Non-continuous 180°C Shelf life ....................................... 1 year at 25°C Package.......................................... 5 & 20 liter container Application Details Application method .................... Air/Airless spray, Brush Nozzle orifice................................. . .018"-.021" Nozzle pressure............................. 200 bar/2900 Psi Pump ratio..................................... Min 54:1 Mixing ratio................................... Base/Hardener 4/ 1by weight Thinner/Cleaner............................ SVT-89 Pot life ............................................ 2 hrs at 20°C Recoat interval min:.................... 24 hrs at 20°C Recoat interval max:................... 21 days at 20°C
Outstanding Characteristics Excellent oil resistance Excellent chemical resistance against acids, and alkalies. Corrosion resistance in moderately to severely environment Suitable for steel & concrete exposed to splash. Spillage, fumes of corrosive chemical. Suitable as a lining in storage tanks, on substate exposed to immersion and splash of seawater.
Recommended Use As a protective coating in industrial and marine structures, Over concrete or metal surfaces. Resistant to a variety of chemicals, fuel oils & solvents. As a general purpose is suitable for lining storage tanks ship tanks exposed to immersion, splash sea water.
Surface Preparation The surface must be clean and dry. All dirt, grease, mill- scales and any other foreign materials should be removed. Old primed surfaces must be smoothly wire brushed.

	SARV COAT 8969
Epoxy phenolic intermediate COATINGS


Description Sarv coat 8969 is a two component, high performance modified epoxy coating.	Physical Data Finish............................................... Semi Flat Colour............................................. White, Grey Volume Solids............................... 58±2% Specific Gravity............................ 1.4±0.05 gr/cm³ Flash Point..................................... 26°C Dry film Thicknss......................... 100-150 microns Touch dry....................................... 4 hrs at 20°C Hard dry......................................... 7 days at 20°C 6 days at 35°C Thermal Resistance...................... Continuous 160°C Non-continuos 180 °C Theoretical Coverage................... 5.8-3.8 sqm/lit 4.14-2.75 sqm/kg Practical Coverage....................... Depends on loss factor Shelf life ........................................ 1 year at 25°C Package.......................................... 5 & 20 liter container Application Details Application method .................... Air/Airless spray, Brush Nozzle orifice................................. . .018"-.021" Nozzle pressure............................. 200 bar/2900 Psi Mixing ratio................................... Base/Hardener 4/ 1by weight Thinner/Cleaner............................ SVT-89 Pot life ............................................ 2 hrs at 20°C Recoat interval min:.................... 24 hrs at 20°C Recoat interval max:................... 21 days at 20°C
Outstanding Characteristics Excellent oil resistance Excellent chemical resistance against weak acids, alkalies and solvents. Suitable for immersion in warm water. Corrosion resistance in moderately to severely environment.
Recommended Use As a protective coating in tanks lining or steel structures to be immersed or exposed to splash or spillage of sea or potable water, solvents and chemicals.
Surface Preparation The surface must be clean and dry. All dirt, grease, mill- scales and any other foreign materials should be removed. Old primed surfaces must surfaces must be roughenend.

	SARV COAT 8970
Epoxy phenolic primer COATINGS


Description Sarv coat 8970 is a two component, polyamine cured, epoxy phenolic.	Physical Data Finish............................................... Flat Colour............................................. White, Grey, Aluminum Volume Solids............................... 60±2% Specific Gravity............................ 1.4±0.05 gr/cm³ Flash Point..................................... 26°C Dry film Thicknss......................... 50-70 microns Touch dry....................................... 3 hrs at 20°C Hard dry......................................... 7 days at 20°C 6 days at 35°C Thermal Resistance...................... Continuous 160°C Non-continuous 180°C Theoretical Coverage................... 12-8.6 sqm/lit ......................................................... 8.6-6.12 sqm/kg Practical Coverage....................... Depends on loss factor Shelf life ........................................ 1 year at 25°C Package.......................................... 5 & 20 liter container Application Details Application method .................... Air/Airless spray, Brush Nozzle orifice................................. . .018"-.021" Nozzle pressure............................. 200 bar/2900 Psi Pump ratio..................................... Min 45:1 Mixing ratio................................... Base/Hardener 4/ 1by weight Thinner/Cleaner............................ SVT-89 Pot life ............................................ 2 hrs at 20°C Recoat interval min:.................... 24 hrs at 20°C Recoat interval max:................... 21 days at 20°C
Outstanding Characteristics Excellent oil resistance Excellent chemical resistance against weak acids, alkalies and solvents. Suitable for immersion in warm water. Corrosion resistance in moderately to severely environment.
Recommended Use As a protective coating in tanks lining or steel structures to be immersed or exposed to splash or spillage of sea or potable water, solvents and chemicals.
Surface Preparation Remove salt and other contaminants by (high pressure) fresh water cleaning.(For maintenance) Abrasive blasting to Sa 2½ SSPC-10 with a sharp –edged surface profile corresponding to Rugotest No.3, BN9a, Keane- Tator comparator, 2.0 G/S or ISO comparator, medium (G). (For new steel)

	SARV COAT 9519
polyurethane varnish COATINGS


Description Sarv coat 9519 a two component, aliphatic isocyanate cured polyurethane varnish.	Physical Data Finish............................................... Gloss, mate Colour............................................. Non-Pingmented Volume Solids............................... 48±2% Specific Gravity............................ 1.1 ±0.1 gr/Cm³ Flash Point..................................... 30°C Recommended D.F.T................... 30-50 microns Theoretical Coverage................... 16-9.6 sqm/lit 14.5-8.7 sqm/kg Practical Coverage....................... Depends on loss factor Touch dry....................................... 5 hrs at 20°C 3 hrs at 35°C Fully Cured.................................... 1 week at 20°C 5 days at 35°C Thermal Resistance...................... 120°C Shelf life......................................... 1 year at 25°C Package.......................................... 4 & 20 liter container Application Details Application method .................... Air/Airless spray, Brush Nozzle orifice................................. . .017"-.019" Nozzle pressure............................. 150 bar/2200 Psi Application temperature............. 10 to 50°C Mixing ratio................................... as recommended on paint label Thinner/Cleaner............................ SVT-95 Pot life ............................................ 5 hrs at 20 °C Recoat interval min:.................... 16 hrs at 20 °C Recoat interval max:................... None with itself
Outstanding Characteristics Excelent processability High weather and chemical resistance. Excelent gloss retention Easy to clean
Recommended Use For use on polyurethane, epoxy paint system or bare metal where a hard and glossy clear coat is required.
Surface Preparation The surface must be clean and dry. All dirt, grease, mill- scales and other foreign materials should be removed.

	SARV COAT 9520
polyurethane sealer COATINGS


Description Sarv coat 9520 is a two component, isosyanate cured aliphatic polyurethane sealer.	Physical Data Finish............................................... Flat Colour............................................. Non pigmented Volume Solids............................... 40±2% Specific Gravity............................ 1.0 ±0.02 gr/m³ Flash Point..................................... 30°C Dry Film Thickness....................... 20-30 microns Touch dry....................................... 5 hrs at 20°C 3hrs at 35°C Fully cured..................................... 1 week at 20°C 5 days at 35°C Thermal Resistance...................... 120°C Shelf life......................................... 1 year at 25°C Package.......................................... 4& 20 liter container Application Details Application method .................... Air/Airless spray, Brush Nozzle orifice................................. . .017"-.019" Nozzle pressure............................. 150 bar/2200 Psi Mixing ratio................................... Base/Hardener 5/1 by weight Thinner/Cleaner............................ SVT- 95 Pot life ............................................ 5 hrs at 20°C Recoat interval min:.................... 16 hrs at 20°C *Recoat interval max:................. none withitself
Outstanding Characteristics Excellent penetration High chemical & solvent resistance. With the proper topcoat it withstands splash or spillage of water.
Recommended Use For use on concrete, metal surfaces and as an intermediate coat on zinc silicates to minimize popping.
Surface Preparation Sand blasting or wire brushing to a standard of ST2(SA 2.5, SIS 05 5900 ISO 8501-1).For concrete and previously primed surfaces with sarv coat 1983, the surface must be clean and dry. All dirt, grease, mill-scales and any other foreign material should be removed.

SARV COAT 9521

polyurethane top coat COATINGS

Description

Sarv coat 9521 a two component, aliphatic isocyante cured polyurethane topcoat.

Physical Data

Finish............................................... Gloss/Semi gloss

Colour............................................. upon request

Volume Solids............................... 50±3%

Specific Gravity............................ 1.15 ±0.1 gr/m³

Flash Point..................................... 30°C

Recommended D.F.T................... 40-60 microns

Theoretical Coverage................... 12.5-8.3 m²/lit

10.8-7.2 m²/kg

Practical Coverage....................... Depends on loss factor

Touch dry....................................... 2 hrs at 20°C

1.5 hrs at 35°C

Fully Cured.................................... 5 days at 20°C

4 days at 35°C

Thermal Resistance...................... Continuous 90°C

Non-continuous 100°C

Shelf life......................................... 12 months

Package.......................................... 4 & 20 liter container

Application Details

Application method .................... Air/Airless spray, Brush

Nozzle orifice................................. . .017"

Nozzle pressure............................. 150 bar/2200 Psi

Application temperature............. . .5 to 50 °C

Mixing ratio................................... Refer to the can label

Thinner/Cleaner............................ SVT-95

Pot life ............................................ 4 hrs at 20 °C

Recoat interval.............................. Min 16 hrs

Max 72 hrs

Outstanding Characteristics

Excelent corrosion resistance
High weather and chemical resistance.
Excelent gloss and colour retention
Easy to clean

Recommended Use

As a protective finish coat for protection of structural steel where superior performance, attractive appearance, gloss retention and high corrosion resistance is required, shuch as chemical plants, pulp & paper mills, off-shore platforms, petroleum refineries and containers.

Surface Preparation

The surface must be clean and dry. All dirt, grease, mill- scales and any other foreign materials should be removed. For old primed surfaces, it may be necessary to roughen the surface.

Revised

May-2010

SARV RANG PRODUCT DATA

SARV COAT 1761

pure silicone COATINGS

Description

Physical Data

Application Details

Outstanding Characteristics

Recommended Use

Surface Preparation

SARV COAT 1861

acrylic silicone COATINGS

Description

Physical Data

Application Details

Outstanding Characteristics

Recommended Use

Surface Preparation

SARV COAT 1862

acrylics silicone COATINGS

Description

Physical Data

Application Details

Outstanding Characteristics

Recommended Use

Surface Preparation

SARV COAT 1862-7

coloured acrylic silicone COATINGS

Description

Physical Data

Application Details

Outstanding Characteristics

Recommended Use

Surface Preparation

SARV COAT 1862-8

coloured acrylic silicone COATINGS

Description

Physical Data

Application Details

Outstanding Characteristics

Recommended Use

Surface Preparation

SARV COAT 1983

3 pack inorcanic zinc silicate COATINGS

Description

Physical Data

Application Details

Outstanding Characteristics

Recommended Use

Surface Preparation

SARV COAT 1983-7

2 Pack inorcanic zinc silicate COATINGS

Description

Physical Data

Application Details

Outstanding Characteristics

Recommended Use

Surface Preparation

SARV COAT 1983-8

2 pack inorcanic zinc silicate shopprimer COATINGS

Description

Physical Data

Application Details

Outstanding Characteristics

Recommended Use

Surface Preparation

SARV COAT 1983-9

2 pakc silico silicate primer

Description

Physical Data

Application Details

Outstanding Characteristics

Recommended Use

Surface Preparation

SARV COAT 2729

vinyl sealer COATINGS

Description

Physical Data

Application Details

Outstanding Characteristics

Recommended Use
